972K Wheel Loader Specifi cations
Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.60
6.02
4.00
5.23
3220
10'6"
3187
10'5"
1363
4'5"
3004
9'10"
103
4"
9178
30'2"
6195
20'4"
14951
49'1"
18658
41,124
19985
44,048
16289
35,901
17608
38,808
202
45,482
26284
57,929
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
General Purpose – Pin On
Teeth and Bolt-On Teeth and
Segments Teeth Edges Segments Teeth
4.60 4.40 4.80 4.80 4.60
6.02 5.75 6.28 6.28 6.02
4.00 3.80 4.10 4.10 3.90
5.23 4.97 5.36 5.36 5.10
3271 3271 3220 3271 3271
10'8" 10'8" 10'6" 10'8" 10'8"
3033 3033 3154 2999 2999
9'11" 9'11" 10'4" 9'10" 9'10"
1500 1500 1392 1528 1528
4'11" 4'11" 4'6" 5'0" 5'0"
3209 3209 3049 3254 3254
10'6" 10'6" 10'0" 10'8" 10'8"
103 73 103 103 73
4" 2.8" 4" 4" 2.8"
9402 9402 9223 9447 9447
30'11" 30'11" 30'4" 31'0" 31'0"
6195 6195 6031 6031 6031
20'4" 20'4" 19'10" 19'10" 19'10"
15132 15132 14976 15157 15157
49'8" 49'8" 49'2" 49'9" 49'9"
18476 18733 18683 18500 20705
40,722 41,288 41,179 40,775 45,634
19799 20059 20017 19830 22448
43,638 44,210 44,118 43,705 49,475
16104 16343 16317 16132 18062
35,494 36,021 35,963 35,554 39,810
17422 17662 17642 17455 19773
38,398 38,927 38,884 38,471 43,580
201 214 196 194 207
45,173 48,227 44,075 43,766 46,655
26422 26258 26212 26350 26186
58,233 57,873 57,770 58,074 57,714
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
18
