972K Wheel Loader Specifi cations
Dimensions
AlldimensionsareapproximateandbasedonL3MichelinXHA2tires.
10
15
11
5
1 2
3 12
13
14
9 4 8
6 7
1 HeighttoTopofROPS 3547mm 11'7"
2 HeighttoTopofExhaustPipe 3518mm 11'6"
3 HeighttoTopofHood 2828mm 9'3"
4 GroundClearancewith26.5R25(SeeTireOptionChartforOtherTires) 475mm 1'6"
5 B­PinHeight–Standard 4456mm 14'7"
B­PinHeight–HighLift 4792mm 15'8"
6 CenterLineofRearAxletoEdgeofCounterweight 2473mm 8'1"
7 Wheelbase 3450mm 11'3"
8 B­PinHeight@Carry–Standard 689mm 2'3"
9 CenterLineofRearAxletoHitch 1725mm 5'7"
10 RackBack@MaximumLift 56degrees
11 DumpAngle@MaximumLift 48degrees
12 RackBack@Carry 50degrees
13 RackBack@Ground 41degrees
14 HeighttoCenterLineofAxle 798mm 2'7"
15 LiftArmClearance 3804mm 12'6"
LiftArmClearance@HighLift 4153mm 13'6"
