Cat
®
TH406
Telehandler
Specifications
Engine
Model
Engine Model (Standard)
Cat ® C4.4 Mechanical DITAAC
Engine Model (Optional) Cat ® C4.4 Electronic DITAAC-ACERT ™
Gross Power (Standard) 74.5 kW 100 hp
Gross Power (Optional) 93.1 kW 125 hp
Maximum Torque (Standard) 410 Nm at 1400 rpm
Maximum Torque (Optional) 496 Nm at 1400 rpm
Bore 105 mm 4.13 in
Stroke 127 mm 4.99 in
Displacement 4.4 L 268.5 in 3
Weights
Operating Weight 7200 kg 15,870 lb
Operating Specifications
Rated Load Capacity 3700 kg 8,150 lb
Maximum Lift Height 6.10 m 20 ft
Maximum Forward Reach 3.11 m 10 ft 2 in
Top Travel Speed 40 kph 25 mph
Capacity at Max Height 2500 kg 5,500 lb
Capacity at Max Reach 1500 kg 3,300 lb
Turning Radius over Tires 3.70 m 12 ft 2 in
Service Refill Capacities
Fuel Tank 150 L 39.63 gal
Hydraulic Tank 90 L 23.78 gal
Tires
Standard 15.5/80-24 16PR
Optional 400/80 R24 Power CL
460/70 R24 XMCL
15.50 x 25 SGL
Brakes
• Service brakes are inboard wet disc brakes on front axle
• Parking brakes are mechanical on front axle
Hydraulic System
Maximum System Pressure 250 bar 3,625 psi
Maximum Pump Flow 150 L/min 39.63 gal/min
Pump Type Variable displacement
load sensing axial piston pump
Auxiliary Hydraulic Supply 80 L/min 21.13 gal/min
(Intermittent)
Auxiliary Hydraulic Supply
60 L/min 15.85 gal/min
(Continuous)
• Auxiliary Hydraulic Circuit used for all attachments
equipped with cylinders or other hydraulic components.
Consists of valves, controls, and hydraulic lines.
Transmission Speeds
Forward — 1 7 kph 4.3 mph
Forward — 2 12 kph 7.45 mph
Forward — 3 21 kph 13 mph
Forward — 4 32 kph 19.8 mph
Forward — 5 40 kph 25 mph
Reverse — 1 7 kph 4.3 mph
Reverse — 2 12 kph 7.45 mph
Reverse — 3 21 kph 13 mph
Boom Performance
Boom Up 5 Seconds
Boom Down 4 Seconds
Tele In 4.5 Seconds
Tele Out 5 Seconds
Tilt Forward (dump) 3 Seconds
Tilt Backward 3 Seconds
Combined — Up and Out 8 Seconds
Combined — Down and In 6 Seconds
Drawbar Pull 82.4 kW 8400 kg 18,520 lb
Drawbar Pull 86.8 kW 8849 kg 19,510 lb
Instruments
• Engine speed, boom angle, machine speed, operation hours,
% of continuous flow selected, gear selected and direction
