972K Wheel Loader Specifi cations
Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.40
5.75
3.80
4.97
3220
10'6"
3200
10'6"
1362
4'5"
2993
9'9"
103
4"
9167
30'1"
6205
20'5"
14940
49'1"
18263
40,252
19578
43,150
15902
35,049
17213
37,937
203
45,788
26642
58,718
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
General Purpose – Fusion QC
Teeth and Bolt-On Teeth and
Segments Teeth Edges Segments Teeth
4.40 4.20 4.60 4.60 4.40
5.75 5.49 6.02 6.02 5.75
3.80 3.60 4.00 4.00 3.80
4.97 4.71 5.23 5.23 4.97
3271 3271 3220 3271 3271
10'8" 10'8" 10'6" 10'8" 10'8"
3047 3047 3157 3003 3003
9'11" 9'11" 10'4" 9'10" 9'10"
1500 1500 1397 1535 1535
4'11" 4'11" 4'7" 5'0" 5'0"
3198 3198 3050 3255 3255
10'5" 10'5" 10'0" 10'8" 10'8"
103 73 103 103 73
4" 2.8" 4" 4" 2.8"
9391 9391 9224 9448 9448
30'10" 30'10" 30'4" 31'0" 31'0"
6205 6205 6211 6211 6211
20'5" 20'5" 20'5" 20'5" 20'5"
15122 15122 14971 15154 15154
49'8" 49'8" 49'2" 49'9" 49'9"
18082 18439 18113 17931 18282
39,853 40,639 39,921 39,520 40,293
19393 19767 19425 19239 19606
42,742 43,566 42,812 42,403 43,212
15719 16060 15761 15577 15912
34,645 35,396 34,738 34,332 35,072
17028 17383 17070 16884 17233
37,530 38,312 37,622 37,212 37,982
202 216 195 194 207
45,479 48,572 43,941 43,632 46,510
26780 26616 26700 26838 26675
59,022 58,662 58,847 59,151 58,791
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
