36 VEGACOM 557 Siemens
6.2 Complete overview on process image of measured values in VEGACOM
Data
component
Data word VEGALOG
in VEGACOM
in
VEGACOM
VEGAMET
509, 512
VEGAMET 513
514, 515, 614
VEGAMET
509, 512
VEGAMET 513
514, 515, 614
DB3 DW 0 DCS 1 - - - -
DB3 DW 2 DCS 2 - - CH1 MET1 DCS1 MET1
DB3 DW 4 DCS 3 - - CH1 MET2 DCS1 MET2
DB3 DW 6 DCS 4 MET1 CH1 - CH1 MET3 DCS1 MET3
DB3 DW 8 DCS 5 MET1 CH2 - CH1 MET4 DCS1 MET4
DB3 DW 10 DCS 6 MET1 CH3 - CH1 MET5 DCS1 MET5
DB3 DW 12 DCS 7 MET2 CH1 - CH1 MET6 DCS1 MET6
DB3 DW 14 DCS 8 MET2 CH2 MET1 DCS1 CH1 MET7 DCS1 MET7
DB3 DW 16 DCS 9 MET2 CH3 MET1 DCS2 CH1 MET8 DCS1 MET8
DB3 DW 18 DCS 10 MET3 CH1 MET1 DCS3 CH1 MET9 DCS1 MET9
DB3 DW 20 DCS 11 MET3 CH2 MET1 DCS4 CH1 MET10 DCS1 MET10
DB3 DW 22 DCS 12 MET3 CH3 MET1 DCS5 CH1 MET11 DCS1 MET11
DB3 DW 24 DCS 13 MET4 CH1 MET1 DCS6 CH1 MET12 DCS1 MET12
DB3 DW 26 DCS 14 MET4 CH2 MET1 DCS7 CH1 MET13 DCS1 MET13
DB3 DW 28 DCS 15 MET4 CH3 MET2 DCS1 CH1 MET14 DCS1 MET14
DB3 DW 30 DCS 16 MET5 CH1 MET2 DCS2 CH1 MET15 DCS1 MET15
DB3 DW 32 DCS 17 MET5 CH2 MET2 DCS3 CH2 MET1 -
DB3 DW 34 DCS 18 MET5 CH3 MET2 DCS4 CH2 MET2 DCS2 MET1
DB3 DW 36 DCS 19 MET6 CH1 MET2 DCS5 CH2 MET3 DCS2 MET2
DB3 DW 38 DCS 20 MET6 CH2 MET2 DCS6 CH2 MET4 DCS2 MET3
DB3 DW 40 DCS 21 MET6 CH3 MET2 DCS7 CH2 MET5 DCS2 MET4
DB3 DW 42 DCS 22 MET7 CH1 MET3 DCS1 CH2 MET6 DCS2 MET5
DB3 DW 44 DCS 23 MET7 CH2 MET3 DCS2 CH2 MET7 DCS2 MET6
DB3 DW 46 DCS 24 MET7 CH3 MET3 DCS3 CH2 MET8 DCS2 MET7
DB3 DW 48 DCS 25 MET8 CH1 MET3 DCS4 CH2 MET9 DCS2 MET8
DB3 DW 50 DCS 26 MET8 CH2 MET3 DCS5 CH2 MET10 DCS2 MET9
DB3 DW 52 DCS 27 MET8 CH3 MET3 DCS6 CH2 MET11 DCS2 MET10
DB3 DW 54 DCS 28 MET9 CH1 MET3 DCS7 CH2 MET12 DCS2 MET11
DB3 DW 56 DCS 29 MET9 CH2 MET4 DCS1 CH2 MET13 DCS2 MET12
DB3 DW 58 DCS 30 MET9 CH3 MET4 DCS2 CH2 MET14 DCS2 MET13
DB3 DW 60 DCS 31 MET10 CH1 MET4 DCS3 CH2 MET15 DCS2 MET14
DB3 DW 62 DCS 32 MET10 CH2 MET4 DCS4 CH3 MET1 DCS2 MET15
DB3 DW 64 DCS 33 MET10 CH3 MET4 DCS5 CH3 MET2 -
DB3 DW 66 DCS 34 MET11 CH1 MET4 DCS6 CH3 MET3 DCS3 MET1
DB3 DW 68 DCS 35 MET11 CH2 MET4 DCS7 CH3 MET4 DCS3 MET2
DB3 DW 70 DCS 36 MET11 CH3 MET5 DCS1 CH3 MET5 DCS3 MET3
DB3 DW 72 DCS 37 MET12 CH1 MET5 DCS2 CH3 MET6 DCS3 MET4
DB3 DW 74 DCS 38 MET12 CH2 MET5 DCS3 CH3 MET7 DCS3 MET5
DB3 DW 76 DCS 39 MET12 CH3 MET5 DCS4 CH3 MET8 DCS3 MET6
DB3 DW 78 DCS 40 MET13 CH1 MET5 DCS5 CH3 MET9 DCS3 MET7
DB3 DW 80 DCS 41 MET13 CH2 MET5 DCS6 CH3 MET10 DCS3 MET8
DB3 DW 82 DCS 42 MET13 CH3 MET5 DCS7 CH3 MET11 DCS3 MET9
DB3 DW 84 DCS 43 MET14 CH1 MET6 DCS1 CH3 MET12 DCS3 MET10
DB3 DW 86 DCS 44 MET14 CH2 MET6 DCS2 CH3 MET13 DCS3 MET11
Sorting acc. to
VEGAMET addresses
Sorting acc. to
channels / DCS indices
Supplement
