VEGACOM 557 Siemens
21
Setup
Select with F7 in the field program name the programming library COMLIB02. For interpreter
selection push F3:
-> PROGRAM CHOICE -> CHOICE-> TRANSMIT –> SIMATIC S5 / COM 525
P R O C E D U R E
—————————————————————————————————————
Source:
Destination:
VOLUME:
FD
FD
DRIVE:
C
C
INTERFACE NO.:
PROGRAM NAME:
COMLIB02
PROGR1
COMPONENT:
RK
Source:
COMPONENT
NAME
VERSION
RK
RK512
01
F1
|
F2
|
F3
|
F4
|
F5
|
F6
|
F7
|
F8
TRANS- |
|
|
|
|
|
|
MIT
|
|
|
|
|
|
HELP
|
EXIT
Issue short description
To check the settings, a short description can be issued.
Change to the overview menu: Basic pattern F1 -> Selection F4 -> Information F3 -> FD F2 ->
Short description. The menu appears:
-> PROGRAM CHOICE -> CHOICE-> SIMATIC S5 / COM 525
INFO
—————————————————————————————————————
VOLUME:
FD
DRIVE:
C
PROGRAM NAME:
PROGR1
COMPONENT:
RK
System name:
system
Creator:
tgr
Creation date:
03.11.94
Data type
Element name
Number
Data type
Number
Interpreter:
RK512
01 1
Order block
1
Procedure:
P3964R
01 1
Print param:
DRUCK_PARA
Total number:
3
elements
Program length:
9321
words
F1
|
F2
|
F3
|
F4
|
F5
|
F6
|
F7
|
F8
SHORT
|
|
|
| ORDER
|
|
|
DESCR. |
|
|
| BLOCK
|
|
HELP
|
EXIT
The interpreter must be set to RK512 and the procedure to P3964R.
Save programm in EPROM
The program is transferred with an EPROM programming device (PROMMER) to the EPROM
memory module for the CP. For this, you have the program PROM 525. It is called up in the S5
program in directory Change/further... (directory: \STEP 5).
