VEGA VEGACOM 557 Siemens 3964 and 3964 R procedure with RK 512 User Manual
Page 32
32
VEGACOM 557 Siemens
S5 functional component
Saving of the VEGAMET data in the PLC data component
Data word
DW
0
00
00
00
80
7 pieces
2
00
00
00
80
reserved, are not used
12
00
00
00
80
14
HB
LB
ME
STAT
7 pieces
16
HB
LB
ME
STAT
VEGAMET address 1
18
HB
LB
ME
STAT
20
HB
LB
ME
STAT
7 pieces
22
HB
LB
ME
STAT
VEGAMET address 2
24
HB
LB
ME
STAT
up to 40
Saving of the VEGALOG data into PLC data component
Data word
DW
0
HB
LB
ME
STAT
DCS 1
2
HB
LB
ME
STAT
DCS 2
4
HB
LB
ME
STAT
DCS 3
6
HB
LB
ME
STAT
DCS
8
HB
LB
ME
STAT
DCS 5
10
HB
LB
ME
STAT
DCS 6
up to 40
up to DCS 21
Explanation:
HB
LB
=
Indicating value (Highbyte and Lowbyte )
ME
=
Field for measuring unit (will be filled with 0)
STAT
=
Status value
