VEGACOM 557 Siemens
19
Setup
Order switching condition relay
The relays are saved in data component DB5. Therefore it is necessary to enter this data
component in the order. The order number has been set to 2 as we assumed that already an
order for reading the measured values is available.
-> CHOICE -> ORDER BLOCK -> SIMATIC S5 / COM 525
O R D E R P R O G R .
—————————————————————————————————————
DRIVE: C PROGRAM: PROGR1 COMPONENT: RK
O R D E R
Order - no:
002
Order:
FETCH
Order - Type
Data component
CPU - no:
1
DB - no:
005
Source - word adress:
00000 D 0000 H
Optionally with coorindation - tag: .
F1
|
F2
|
F3
|
F4
|
F5
|
F6
|
F7
|
F8
TO
|
BACK-
|
FOR-
|
| DELETE
|TAKE OVER |
|
PRINTER |
WARDS
|
WARD
|
|
ORDER
|ORDER
|
HELP
|
EXIT
Procedure
For determination of the procedure with the transmission parameters, the procedure compo-
nents can be taken over out of the programming library COMLIB02.
Change to the transmission menu: Basic pattern F1 -> Choice F2 -> Transfer F5 -> FD-FD.
The menu appears:
-> PROGRAM CHOICE -> CHOICE-> SIMATIC S5 / COM 525
T R A N S M I T
—————————————————————————————————————
Source:
Destination:
VOLUME:
FD
FD
DRIVE:
C
C
INTERFACE NO.:
PROGRAM NAME:
COMLIB02
PROGR1
COMPONENT:
RK
System name:
STANDARD LIBRARY
x
Creator:
GW Karlsruhe
x
Creation date:
23.06.88
08.11.94
F1
|
F2
|
F3
|
F4
|
F5
|
F6
|
F7
|
F8
|
|
INTER-
|
|
ORDER
|
|
|
|
PRETER
|PROCEDURE | PARAM.
|
BLOCK
|
HELP
|
EXIT
