H8163-CB
INSTALLATION GUIDE
MODBUS POINT MAP
Int
Float
R/W NV Model
Description
Notes
1
257/258 R
NV
Energy Consumption, kWh, Low-word integer
Both 257/258 and 259/260 have the same floating point value.
2
259/260 R
NV
Energy Consumption, kWh, High-word integer
3
261/262 R
Real Power, kW
4
263/264 R
Reactive Power, kVAR
5
265/266 R
Apparant Power, kVA
6
267/268 R
Total Power Factor
7
269/270
R
-1
Not Applicable - reads 0xFFFF/NaN (int/float)
-2
Avg Voltage, L-L, ave of 1
-3
Avg Voltage, L-L, ave of 3
8
271/272
R
-1
Avg Voltage, L-N, ave of 1
R
-2
Avg Voltage, L-N, ave of 2
R
-3
Avg Voltage, L-N, ave of 3
9
273/274
R
-1
Avg Current, average of 1
R
-2
Avg Current, average of 2
R
-3
Avg Current, average of 3
10
275/276
R
-1
Real Power, phase A (same as Real Power, kW (3))
-2/-3
Real Power, phase A
11
277/278
R
-1
Not Applicable – reads as 0xFFFF/NaN (int/float)
-2/3
Real Power, phase B
12
279/280
R
-1/-2
Not Applicable – reads as 0xFFFF/NaN (int/float)
-3
Real Power, phase C
13
281/282
R
-1
Power Factor, phase A (Same as Total PF (6))
-2/-3
Power Factor, phase A
14
283/284
R
-1
Not Applicable – reads 0xFFFF/NaN (int/float)
-2/-3
Power Factor, phase B
15
285/286
R
-1/-2
Not Applicable – reads 0xFFFF/NaN (int/float)
-3
Power Factor, phase C
16
287/288
R
-1
Not Applicable – reads 0xFFFF/NaN (int/float)
-2/-3
Voltage, phase A-B
17
289/290
R
-1/-2
Not Applicable – reads 0xFFFF/NaN (int/float)
-3
Voltage, phase B-C
18
291/292
R
-1/-2
Not Applicable – reads 0xFFFF/NaN (int/float)
-3
Voltage, phase A-C
19
293/294
R
-1
Voltage, phase A-N (Same as Avg. L-N (8))
-2/-3
Voltage, phase A-N
20
295/296
R
-1
Not Applicable – reads 0xFFFF/NaN (int/float)
-2/-3
Voltage, phase B-N
21
297/298
R
-1/-2
Not Applicable – reads 0xFFFF/NaN (int/float)
-3
Voltage, phase C-N
22
299/300
R
-1
Current, phase A (Same as Avg. Current (9))
-2/-3
Current, phase A
R: R = Read-only, R/W = read from either format, write to integer format only
NV: Value is stored in non-volatile memory
