H8163-CB INSTALLATION GUIDE
DIVISOR TABLE
MB Point
Unit/Description
kWh
100A 200A 300/400A 800A 1600A 2400A
1 kWh 128 64 32 16 8 4
2 kWh 1.953E-3 9.765E-4 4.8828E-4 2.4414E-4 1.2207E-4 6.1035E-5
3 kW 250 125 62.5 31.25 15.625 7.8125
4 kVAR 250 125 62.5 31.25 15.625 7.8125
5 kVA 250 125 62.5 31.25 15.625 7.8125
6 PF 32768 32768 32768 32768 32768 32768
7 V_LL 32 32 32 32 32 32
8 V_LN 64 64 64 64 64 64
9 Amps 256 128 64 32 16 8
10 kW_a 1000 500 250 125 62.5 32.25
11 kW_b 1000 500 250 125 62.5 32.25
12 kW_c 1000 500 250 125 62.5 32.25
13 PF_a 32768 32768 32768 32768 32768 32768
14 PF_b 32768 32768 32768 32768 32768 32768
15 PF_c 32768 32768 32768 32768 32768 32768
16 V_ab 32 32 32 32 32 32
17 V_bc 32 32 32 32 32 32
18 V_ac 32 32 32 32 32 32
19 V_an 64 64 64 64 64 64
20 V_bn 64 64 64 64 64 64
21 V_cn 64 64 64 64 64 64
22 Amps_a 256 128 64 32 16 8
23 Amps_b 256 128 64 32 16 8
24 Amps_c 256 128 64 32 16 8
25 kWd 250 125 62.5 31.25 15.625 7.8125
26 kWd 250 125 62.5 31.25 15.625 7.8125
27 kWd 250 125 62.5 31.25 15.625 7.8125
28 kVARd 250 125 62.5 31.25 15.625 7.8125
29 kVARd 250 125 62.5 31.25 15.625 7.8125
30 kVARd 250 125 62.5 31.25 15.625 7.8125
