H8163-CB INSTALLATION GUIDE
MULTIPLIER TABLE
MB Point
Unit/Description
kWh
100A 200A 300/400A 800A 1600A 2400A
1 kWh 0.007813 0.015625 0.03125 0.0625 0.125 0.25
2 kWh 512 1024 2048 4096 8192 16384
3 kW 0.004 0.008 0.016 0.032 0.064 0.128
4 kVAR 0.004 0.008 0.016 0.032 0.064 0.128
5 kVA 0.004 0.008 0.016 0.032 0.064 0.128
6 PF 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05
7 V_LL 0.03125 0.03125 0.03125 0.03125 0.03125 0.03125
8 V_LN 0.015625 0.015625 0.015625 0.015625 0.015625 0.015625
9 Amps 0.003906 0.007813 0.015625 0.03125 0.0625 0.125
10 kW_a 0.001 0.002 0.004 0.008 0.016 0.032
11 kW_b 0.001 0.002 0.004 0.008 0.016 0.032
12 kW_c 0.001 0.002 0.004 0.008 0.016 0.032
13 PF_a 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05
14 PF_b 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05
15 PF_c 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05 3.05E-05
16 V_ab 0.03125 0.03125 0.03125 0.03125 0.03125 0.03125
17 V_bc 0.03125 0.03125 0.03125 0.03125 0.03125 0.03125
18 V_ac 0.03125 0.03125 0.03125 0.03125 0.03125 0.03125
19 V_an 0.015625 0.015625 0.015625 0.015625 0.015625 0.015625
20 V_bn 0.015625 0.015625 0.015625 0.015625 0.015625 0.015625
21 V_cn 0.015625 0.015625 0.015625 0.015625 0.015625 0.015625
22 Amps_a 0.003906 0.003906 0.003906 0.003906 0.003906 0.003906
23 Amps_b 0.003906 0.003906 0.003906 0.003906 0.003906 0.003906
24 Amps_c 0.003906 0.003906 0.003906 0.003906 0.003906 0.003906
25 kWd 0.004 0.008 0.016 0.032 0.064 0.128
26 kWd 0.004 0.008 0.016 0.032 0.064 0.128
27 kWd 0.004 0.008 0.016 0.032 0.064 0.128
28 kVARd 0.004 0.008 0.016 0.032 0.064 0.128
29 kVARd 0.004 0.008 0.016 0.032 0.064 0.128
30 kVARd 0.004 0.008 0.016 0.032 0.064 0.128
