Page 9
VERIS INDUSTRIES
™
H8126-CB
INSTALLATION GUIDE
Z203167-0A
PAGE 9
©2009 Veris Industries USA 800.354.8556 or +1(0)503.598.4564 / [email protected]
10092
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
NPT
NPA
OR
WR
Units
Range
Description
ADI
30
Y
N
0-65535
Firmware Version
ADI
31
Y
N
0-65535
Firmware Revision
ADI
32
Y
N
0-65535
Serial Number LSW
ADI
33
Y
N
0-65535
Serial Number MSW
BO
1
Y
N
0=NA
1=Reset kWh
accumulator
BO
2
Y
N
0=NA
1=Reset peak demand
BO
3
Y
N
0=NA
1=Reset peak kVAR
BO
4
Y
N
0=NA
1=Begin new demand
subinterval
BO
5
Y
N
0=NA
1=Reset phase loss
register
Legend
OR
Object can be overwritted
WR
Object can be written
Range
The AI ranges are based on a 3-phase 480V system with 100A CTs
NPT
Network point type
NPA
Network point address
Units
Engineering units
Description
Point description
Supported N2 Commands
0/0
Time update message
0/4
Poll without acknowledge message
0/5
Poll with acknowledge message
1/1
Read AI command
1/6
Read ADI command
1/2
Read BI command
1/4
Read BO command
2/1
Write AI command
2/2
Write BI command
2/4
Write BO command
7/2/01
Override AI command
7/2/06
Override ADI command
7/2/04
Override BO command
7/3/01
Override release AI request
7/3/06
Override release ADI request
7/3/02
Override release BI request
7/3/04
Override release BO request
F
Identify device type command
