Installation guide – Veris Industries H8126-CB Install User Manual
Page 8
VERIS INDUSTRIES
™
H8126-CB
INSTALLATION GUIDE
Z203167-0A
PAGE 8
©2009 Veris Industries USA 800.354.8556 or +1(0)503.598.4564 / [email protected]
10092
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
NPT
NPA
OR
WR
Units
Range
Description
ADI
1
Y
N
kWh
0-65535
LSW of kWh accumulator. Lower 16 bits of kWh.
ADI
2
Y
N
kWh
0-65535
MSW of kWh accumulator. Upper 16 bits of kWh.
ADI
3
Y
N
0-65535
Phase Loss. Latching Register (bit mapped):
Bit 0: phase A (unpredictable results on phase A)
Bit 1: phase B
Bit 2: phase C
ADI
4
Y
N
0-65535
Date/Time Month 1-12 (LSB) Day 1-31 (MSB)
ADI
5
Y
N
0-65535
Date/Time Year 0-1999 (LSB) Hour 0-23 (MSB)
ADI
6
Y
N
0-65535
Date/Time Minutes 0-59 (LSB) Seconds 0-59 (MSB)
ADI
7
Y
N
Secs
0-65535
High Alarm Delay: sets the minimum time a signal must remain in state before the alarm is set
(default is 30 sec)
ADI
8
Y
N
Secs
0-65535
High Warning Delay: sets the minimum time a signal must remain in state before the warning is
set (default is 30 sec)
ADI
9
Y
N
Secs
0-65535
Low Warning Delay: sets the minimum time a signal must remain in state before the warning is
set (default is 30 sec)
ADI
10
Y
N
Secs
0-65535
Low Alarm Delay: sets the minimum time a signal must remain in state before the alarm is set
(default is 30 sec)
ADI
11
Y
N
0-65535
Count of kWh resets: the number of times the kWh accumulator has been reset (rolls over at
65535)
ADI
12
Y
N
0-65535
Count of Peak Demand Resets: the number of times the peak demand (ADI 26) has been reset
(rolls over at 65535)
ADI
13
Y
N
0-65535
Count of Peak kVAR Resets: the number of times the kVAR (ADI 29) has been reset (rolls over at
65535)
ADI
14
Y
N
0-65535
Count of Elapsed Subintervals: the number of subintervals that have elapsed. Since the demand
(AI 25) is updated every subinterval, this register indicates whether an identical value in AI 25 is
actually the same demand interval or a new interval with a steady load.
ADI
15
Y
N
0-65535
Number of Readings in Present Subinterval: the number of readings taken in the present
subinterval (AI 24 and AI 27). This register acts as an unsigned integer and will increment every
200 msec (5 times per sec).
ADI
16
Y
N
0-65535
Subinterval Length: sets the length of a subinterval. Value = num. of seconds * 5. For sync-to-
comms or sync-to-demand-reset-input (hardware signal), set this to zero.
ADI
17
Y
N
1-6
Number of Subintervals per Demand Interval: sets the number of subintervals that make a single
demand interval. Valid values are 1 to 6. For block demand, set this to 1. Default is 6.
ADI
18
Y
N
100-2400
CT Size
ADI
19
Y
N
1-3
CT Number
ADI
20
Y
N
0-65535
Count of Phase Losses: number of phase losses on any phase (rolls over at 65535)
ADI
21
Y
N
0-65535
Phase Loss Timestamp, Month 1-12 (LSB) Day 1-31 (MSB)
ADI
22
Y
N
0-65535
Phase Loss Timestamp, Year 0-199 (LSB) Hour 1-24 (MSB)
ADI
23
Y
N
0-65535
Phase Loss Timestamp, Minutes 0-59 (LSB) Seconds 0-59 (MSB)
ADI
24
Y
N
0-65535
Last Restart Timestamp, Month 1-12 (LSB) Day 1-31 (MSB)
ADI
25
Y
N
0-65535
Last Restart Timestamp, Year 0-199 (LSB) Hour 1-24 (MSB)
ADI
26
Y
N
0-65535
Last Restart Timestamp, Minutes 0-59 (LSB) Seconds 0-59 (MSB)
ADI
27
Y
N
0-65535
Last kWh Reset Timestamp, Month 1-12 (LSB) Day 1-31 (MSB)
ADI
28
Y
N
0-65535
Last kWh Reset Timestamp, Year 0-199 (LSB) Hour 1-24 (MSB)
ADI
29
Y
N
0-65535
Last kWh Reset Timestamp, Minutes 0-59 (LSB) Seconds 0-59 (MSB)
