n2 objects
NPT
NPA
OR
WR
Units
Range
Description
AI
1
Y
Y
kWh
0-33554432
Consumption
AI
2
Y
Y
kW
0-100.6
Power
AI
3
Y
Y
kVAR
0-100.6
Reactive Power
AI
4
Y
Y
kVA
0-100.6
Apparent Power
AI
5
Y
Y
Volts
0-1.0
Total Power Factor
AI
6
Y
Y
Volts
5-528
Average Voltage L-L
AI
7
Y
Y
Amps
3-305
Average Voltage L-N
AI
8
Y
Y
kW
1-110
Average Current
AI
9
Y
Y
kW
0-33.5
Real Power, Phase A
AI
10
Y
Y
kW
0-33.5
Real Power, Phase B
AI
11
Y
Y
kW
0-33.5
Real Power, Phase C
AI
12
Y
Y
0-1.0
Power Factor, phase A
AI
13
Y
Y
0-1.0
Power Factor, phase B
AI
14
Y
Y
0-1.0
Power Factor, phase C
AI
15
Y
Y
Volts
5-528
Voltage, phase A-B
AI
16
Y
Y
Volts
5-528
Voltage, phase B-C
AI
17
Y
Y
Volts
5-528
Voltage, phase A-C
AI
18
Y
Y
Volts
3-305
Voltage, phase A-N
AI
19
Y
Y
Volts
3-305
Voltage, phase B-N
AI
20
Y
Y
Volts
3-305
Voltage, phase C-N
AI
21
Y
Y
Amps
1-110
Current, phase A
AI
22
Y
Y
Amps
1-110
Current, phase B
AI
23
Y
Y
Amps
1-110
Current, phase C
AI
24
Y
Y
kW Demand
0-100.6
Present Demand Subinterval (the currently accumulating subinterval demand; constantly
changing)
AI
25
Y
Y
kW Demand
0-100.6
Present Demand (updated at the end of every subinterval; the average of the previous N
subintervals [ADI 17])
AI
26
Y
Y
kW Demand
0-100.6
Peak Demand (highest demand value [AI 25] that has occured; a nonvolatile point)
AI
27
Y
Y
kVAR Demand 0-100.6
Present kVAR Subinterval (the currently accumulating subinterval kVAR; constantly changing)
AI
28
Y
Y
kVAR Demand 0-100.6
Present kVAR (updated at the end of every subinterval; the average of the previous N subintervals
[ADI 17])
AI
29
Y
Y
kVAR Demand 0-3072
Peak kVAR (highest kVAR value [ADI 28] that has occured; a nonvolatile point)
BI
1
Y
N
kWh
100A:0.0078125/count
200A:0.015625/count
800A:0.0625/count
1600:0.125/count
300A:0.03125/count
400A:0.03125/count
2400A:0.25/count
Intended as an accumulator (ACM) type. Do not read as binary status.
