Installation Guide
Power Monitoring
E50F2, E50F5
TM
E50F2
Alarm Energy


Two 5-character rows
of display text.
Top row alphanumeric;
Bottom row numeric only
The red Alarm LED lights
when any of the 3 phase
voltages drop below the
selected threshold.
CONTROL POWER
0.1A 50/60 Hz
A B C N 1 2
S
VA VB VC
Neutr
al
EMC G
round
Con
trol
Po
we
r
UL: 90V
L-N
- 600V
L-L
CE: 90V
L-N
- 300V
L-N
VOLTAGE INPUTS
CAT III 50/60 Hz
+
–
Alarm O
utput
Pulse Input LON FT
Shield
SERVICE
(X2) A (X1) (X2) B (X1) (X2) C (X1)
IA IB IC
X2 X1 X2 X1 X2 X1
CT Inputs 1 or 0.333 VAC
E50F5
Alarm Energy


Two 5-character rows
of display text.
Top row alphanumeric;
Bottom row numeric only
The red Alarm LED lights
when any of the 3 phase
voltages drop below the
selected threshold.
The green Energy LED lights
when the pulse 1 input
contacts are active or closed.
CONTROL POWER
0.1A 50/60 Hz
A B C N 1 2
Pulse Inputs
1 2 S
VA VB VC
Neutr
al
EMC G
round
Con
trol
Po
we
r
UL: 90V
L-N
- 600V
L-L
CE: 90V
L-N
- 300V
L-N
VOLTAGE INPUTS
CAT III 50/60 Hz
+
–
Pulse Input 1 Pulse Input 2 LON FT
Shield
SERVICE
(X2) A (X1) (X2) B (X1) (X2) C (X1)
IA IB IC
X2 X1 X2 X1 X2 X1
CT Inputs 1 or 0.333 VAC
Product Diagrams
Display Screen
Diagram


Tx
Rx
ERR
♥
Screen Name or Units
Diagnostic Alert:
indicates that one or
more of the alarm
bits (Binary_Objects
1-15) are active.
Logo
Numeric Data
Alive Indicator
RS-485 Equipped Units Only:
Transmit Data
Receive Data
Receive Data Error
LCD Screen: Buttons:
+
–
(Up)
Select
(Right)
Next
(Down)
Select
(Left)
Back
