38
Push button code
Push key
Code
RANGE
RANGE AUTO/ RANGE MANUAL
REC
REC ON/ REC AVG/ REC OFF
REL
REL ON ref2/ REL OFF
COMP
COMP ON ref1 ref2/ COMP OFF
HOLD
HOLD ON/ HOLD OFF
★
) ref1 is the sub display on the left lower part of the LCD,
ref2 is the sub display value on the right lower part of the
LCD.
ex)
“1 DCV 12.345 mV HIGH 10.000 11.000 crlf”
:
“1”indicates the push button is being operated and
mean the DCV function. The real value is 12.345mV. The
main display shows
“HI”. The left lower part of the LCD
shows 10.000mV and the right lower part of the LCD
shows 11.000mV.
“2 DCV -1.2345 mV crlf”
“2 mA 0 + 04.000mA + 000.00 crlf”
:
“2”indicates the push button is being off and Outputs
the value being displayed on the Main display.
“3 REL ON crlf”
: Indicates the REL % key is being pressed.
Receive Format( PC to DMM )
REL ON ref2
Activates REL %.(If the value is input on
ref2, it sets with value)
REL OFF
Deactivates REL %
REC ON
Activates the record mode to the normal
mode.
REC AVG
Activates the record mode to the AVG
mode.
o. RS-232C interface
Demonstration software is provided with the DMM. The
program is written for windows using MFC. For you own
applications, consult the following;
1. Specification
Baud rate
19200 baud
Parity none
Data length
8 bit
Stop bit
1 bit
2. Transmitte format(DMM to PC)
Output and Input of all data are ASCII String.
Send Format( DMM to PC )
“fun b sign value b unit b cr lf”
fun Function(ASCII
code)
b
blank(0x20)
Sign -(0x2E)/
(0x20)
Value
Measured value(ASCII string)
unit
Unit(ASCII string)
cr
Carriage Return
lf
Line Feed
Function code
Function
Function code
Unit
DCmV
DCV
mV
DCV
DCV
V
ACV
ACV
V
Diode
DIO
V
Ohm/Continuity
OHM/BEP
Ohm/ Kohm/ Mohm
Capacitance
CAP
uF/mF
Frequency
FRQ
Hz/ Khz
uA
DCA/ACA
uA
mA
DCA/ACA
mA
A
DCA/ACA
A
Adaptor
AC/DC1,2,3 TMP
A / tC/ tF
Current out
mA 0, A, B, C, 2
mA
37
