i. Record Mode

The record mode saves minimum (MIN) and maximum
(MAX) values measured for a series of readings. The main
part of the LCD displays the actual reading, the MAX value is
constantly displayed on the lower left hand sub-display while
the MIN value is constantly displayed on the lower right
hand sub-display. Activate the function as follows:

1. Depress the

REC

button on the 196.

2. The DMM 196 will immediately start to record and display

MIN/MAX values on the two lower sub-displays.

3. Press

REC

button a second time and the AVG(average)

reading will be displayed.

4. Press the

REC

button again to return to normal record

mode.

h. Measuring Frequency

WARNING!

Never attempt a frequency measurement with a voltage
source greater than 600V. Determine the voltage of any
unknown frequency source before connecting the
instrument in frequency source before connecting the
instrument in frequency mode.

FUNCTION BLACK

RED

MINIMUM

MAXIMUM

TEST LEAD

READING

COM

0.01Hz 500.00KHz

Measurement Procedure:

1. Disconnect power to circuit to be measured.

2. Plug black test lead into the

COM

input jack.

3. Plug red test lead into the

input jack.

4. Set the rotary switch to the

function.

5. Press the orange push button.

6. Reconnect power to circuit to be measured.

7. Read the frequency on the LCD.
