k. Relative % Mode
The Relative % mode takes the actual reading on the main
display and compares it to a reference value programmed by
the user on the right hand sub-display. The left hand sub-
display will show the percentage the actual reading varies
from the reference value. Activate the function as follows:
1. To use Relative % mode manually select the range for
the function.
2. Depress the REL % button.
3. Depress the EDIT button. The right hand digit under the
REF sub-display will start to flash.
4. Depress REL % or HOLD buttons until correct number is
selected for that display position.
5. Depress the REC button. The next digit to the right of 3
above will start to flash.
6. Repeat steps 4 and 5 until correct values for all four digits
under REF sub-display are entered.
7. After the correct REF value is entered, depress the EDIT
button.
8. Measure the circuit or component being compared to the
programmed reference value. Results will be displayed as
a percentage in the lower left hand left hand sub-display.
9. Depress the REL % button or turn the rotary switch to exit
the function.
j. Compare Mode
The compare mode takes the actual reading on the main
display and compares it to LOW and HIGH values,
programmed by the user, on the sub-displays. This is used
to compare components or measurements for acceptable
readings. Activate the function as follows:
1. To use Compare Mode manually select the correct
range for the function.
2. Depress the COMP button.
3. Depress the EDIT button the right hand digit under the
HIGH sub-display will start to flash.
4. Depress the REL % or HOLD buttons until the correct
number is selected for the position.
5. Depress the REC button. The next digit to the right of 3
above will start to flash.
6. Repeat steps 4 and 5 until the correct values for all eight
digits under LOW and HIGH sub-display are entered.
7. After the correct LOW and HIGH values are entered,
depress the EDIT button.
8. Measure the circuit or component being compared to the
programmed values. Results will be displayed as PASS
for the acceptable readings, LO for low readings, and HI
for high readings.
9. Depress the COMP button or turn the rotary switch to exit
the function.
