Figure 42 Fastener Torques
Fastener Torques
Fastener
Oil Fill Plug – (drive hub)
Rotary Joint
Banjo Bolt
Cap Screws (hubcap)
Wheel Valve Retaining Bolt
Locknut on Wheel Valve Run Tee
Inner/Outer Hose – to Tee
Control Hose – to Wheel Valve
Pressure Transducer
Cover Fasteners – Pneumatic Control Unit
Wheel Bearing End Play – .001 to .005" (0.025 mm to 0.125 mm)
lbs. ft.
20–30
31
140–160 lbs. in.
15
15
16–19
16–19
16–19
10–12
35–45 lbs. in.
N•m
26–40.6
42
15.8–18.1
20
20
22–26
22–26
22–26
14–16
4–6
