Drive axle wheel end service – Spicer TPCS (Tire Pressure Control System) Service Manual User Manual
Page 49
49
Wheel and
Wheel Valve
Figure 38 Drive Axle Wheel Air Line Routing
5. Wheel valve mounting bracket
6.
3
/
8
" male 37° flare run tee,
9
/
16
"–18 straight thread
O-ring on the run
7. Outer tire hose (short)
1. Inner tire hose (long)
2.
3
/
8
" male 37° flare to
3
/
8
" male pipe fitting
3. Wheel valve control hose
4. Wheel valve
*
Note:
Align fitting with tire air
valve before tightening
to tee 6
1
2
3
4
5
6
7
To outer
tire valve stem*
To inner
tire valve stem*
