Spicer Double Cardan Constant Velocity Joint Assemblies - Manual (Page 9)

10
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
DODGE - PLYMOUTH (Continued)
2000 3500 CONV CAB
1330 series, 134" WB Only 5.9L Eng TC to FA 921782-1402 52105840AB
NV4500 Man Trans Model 60 Front axle
NV 241HD Trans Case
1330 series, 138" & 162" WB Only
TC to FA 921782-1402 52105840AB
5.9L Eng NV4500 Man Trans Model 60
Front axle NV 241HD Trans Case
1330 series, 138" & 162" WB Only
TC to FA 921782-1416 52105871AB
5.9L Eng 46RE Auto Trans Model 60
Front axle NV 241HD Trans Case
1330 series, 138" & 162" WB Only
TC to FA 921782-1601 52105862AB
8.0L & 5.9L Turbo Diesel
47RE Auto Trans Model 60 Front axle
NV 241HD Trans Case
1330 series, 138" & 162" WB Only 5.9L TC to FA
921782-1416 52105871AB
Turbo Diesel A636 Man Trans Model 60
Front axle NV 241HD Trans Case
1330 series, 138" & 162" WB Only 5.9L
TC to FA 921782-1924 52105866AB
Turbo Diesel NV5600 Man. Trans. Model
60 Front axle NV 241HD Trans Case
1330 series, 138" & 162" WB Only
TC to FA 921782-1416 52105871AB
8.0L Eng. A636 Man Trans Model 60
Front axle NV 241HD Trans Case
2000 3500 CLUB CAB
1330 series, 154" WB Only 5.9L Eng TC to FA 921782-1402 52105840AB
NV4500 Man Trans Model 60 Front axle
NV 241HD Trans Case
1330 series, 154" WB Only 8.0L Eng
TC to FA 921782-1416 52105871AB
46RE Auto Trans Model 60 Front axle
NV 241HD Trans Case
1330 series, 154" WB Only 5.9L Turbo
TC to FA 921782-1924 52105866AB
Diesel NV5600 Man Trans Model 60
Front axle NV 241HD Trans Case
1330 series, 154" WB Only 5.9L Turbo
TC to FA 921782-1416 52105871AB
Diesel A636 Man Trans Model 60 Front
axle NV 241HD Trans Case
1330 series, 154" WB Only 5.9L Turbo
TC to FA 921782-1601 52105862AB
Diesel 47RE Auto Trans Model 60 Front
axle NV 241HD Trans Case
1330 series, 154" WB Only .0L Eng
TC to FA 921782-1416 52105871AB
8A636 Man Trans Model 60
Front axle NV 241HD Trans Case
1330 series, 154" WB Only 8.0L Eng
TC to FA 921782-1601 52105862AB
47RE Auto Trans Model 60 Front axle
NV 241HD Trans Case
FORD
1990-94 BRONCO
1330 Series, E40D Auto Trans., TC to RA 915841-1008 F0TA-4602-ZA 23.350 Not Available
4.9L (1992-90), 5.0L, 5.8L Eng. F1TZ-4602-Z
w/3.08 & 3.55 Axle Ratios
1330 Series, Manual 5-Spd. w/O.D.,
TC to RA 915841-1225 E9TA-4602-NB 25.880 Not Available
Mazda R2 & ZF H.D., 5-Spd. w/O.D. E9TZ-4602-AC
Wide Ratio Trans. 4.9L (1992-90) & 5.0L
Eng. w/3.08, 3.55 or 4.10 Axle Ratios
