18
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
FORD (Continued)
1989 RANGER
1310 Series Short W.B., 4-Spd. Auto., TC to RA 915554-2828 E97A-4602-AB 40.570 Not Available
5-Spd. Manual, 2.3l, 2.9L
1210/1310 Series Short W.B., 4-Spd.
TC to FA 914887-1423 E77A-4A376-DA 26.500 Not Available
Automatic, 5-Spd. E7TZ-4A376-B
Manual w/STX Trim Package, 2.9 L.
1210/1310 Series Short W.B.,
TC to RA 915554-2828 E97A-4602-AB 40.570 Not Available
4-Spd. Automatic, 5-Spd. E9TZ-4602-H
Manual w/STX Trim Package, 2.9 L.
1210 Series Long W.B.,
TC to FA 914887-1423 E77A-4A376-DA 26.500 Not Available
4-Spd. Automatic, 5-Spd.
Manual w/STX Trim Package, 2.9L
1210 Series Super Cab, 4-Spd. Auto.,
TC to FA 914887-1423 E77A-4A376-DA 26.500 Not Available
5-Spd. Man. w/STX Trim Package, 2.9L E7TZ-4A376-B
1988 RANGER
1210 Series Short W.B., 4-Spd. TC to RA 914110-2814 E77A-4602-AFA 39.810 919990-3400 26.25
Automatic, 5-Spd Manual w/STX
Trim Package, 2.3L, 2.9L
1210 Series, 4-Spd. Auto., 5-Spd.
TC to FA 914887-1423 E77A-4A376-DA 26.500 Not Available
Manual w/STX Trim Package, 2.9L E7TZ-4A376-B
1987 RANGER
1210 Series, 4-Spd. Automatic TC to FA 914887-1423 E77A-4A376-DA 26.500 Not Available
w/STX Trim Package, 2.9L E7TZ-4A376-B
1210 Series Short W.B, 4-Spd. Auto. TC to RA 914110-2814 E77A-460Z-AFA 39.810 919990-3400 26.25
w/STX Trim Package, 2.9L
1210 Series, 5-Spd. Manual w/O.D.,
TC to FA 914887-1207 E77A-4A376-CA 24.000 Not Available
w/STX Trim Package, 2.9L E7TZ-4A376-A
1210 Series, 5-Spd. Manual TC to FA 914887-1423 E77A-4A376-DA 26.500 Not Available
w/O.D., 2.9L E7TZ-4A376-B
1210 Series Short W.B., 5-Spd. Man. TC to FA 914110-3029 E77A-4602-AEA 42.280 919990-3400 28.72
w/O.D., 2.3L, 2.9L; 2.9L w/STX E5TZ-4602-T
Trim Package
1986 RANGER
1210 Series Short W.B., 4-Spd. TC to RA 914282-2827 E67A-4602-EA 40.210 919976-3400 26.66
Automatic, 2.9L E6TZ-4602-F
1210 Series Short W.B., 5-Spd. TC to RA 914282-3110 E67A-4602-GA 42.680 919976-3400 29.12
Manual w/O.D., 2.3L, 2.3D E6TZ-4602-H
1983-85 RANGER
1210 Series Short W.B., C5 TC to RA 913633-3228 E47A-4602-LA 44.250 919990-3400 30.69
Automatic w.2.8L, M4 Manual E3TZ-4602-AB
w/2.3L, 2.8L E37A-4602-FB
1210 Series Short W.B., 5-Spd. TC to RA 913633-3029 E37A-4602-JB 42.280 919990-3400 28.72
Manual w/O.D., 2.3L, 2.8L, 2.3D E3TZ-4602-AC
1985 RANGER
1210 Series Short W.B., 4-Spd. TC to RA 913633-2814 E57A-4602-JB 39.810 919990-3400 26.25
Automatic, 2.3L, 2.8L E5TZ-4602-U
ISUZU
1999 RODEO/AMIGO
6 Cyl. Engine, Man. trans. TC to FA 920683-0208 8971253012 17.53 Not Available
1999 RODEO/AMIGO
6 Cyl. Engine, Auto trans. TC to FA 920694-0824 8971253022 24.03 Not Available
1999 FRONTERA
4 Cyl. Engine, Man. trans. Long W.B. TC to FA 920694-0116 8971253031 13.890 Not Available
1998-99 RODEO/AMIGO
4 Cyl. Engine, Man. trans. TC to FA 920694-0116 8971253031 13.890 Not Available
