17
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
FORD (Continued)
1979 F250, F350
1330 Series, Part Time Transfer TC to FA 910721-1618 D9TZ-4602-W 28.031 Not Available
Case, 351, 400 Eng. w/Automatic
Trans. and 133" Wheel Base
1330 Series, Part Time Transfer
TC to FA 910721-1209 D9TZ-4602-Y 23.750 Not Available
Case, 300 Eng. w/Manual Trans.
and 133" & 155" Wheel Base
1330 Series, Full Time Transfer Case,
TC to FA 910721-1912 D9TZ-4602-X 30.844 Not Available
351, 400 Eng. w/Automatic Trans.
1330 Series, Full Time Transfer Case,
TC to FA 910721-1801 D9TZ-4602-AA 29.500 Not Available
351, 400 Eng. w/Automatic Trans.
and 133" & 155" Wheel Base
1979 F250, F350 WITH SNOW PLOW OPTION
1330 Series, Part Time Trans. Case, TC to FA 910721-1507 D9TZ-4602-Z 26.688 Not Available
351, 400 Eng. w/Auto. Trans. and 133"
& 155" Wheel Base
1998 RANGER
2.3L, 3.0L, 4.0L Automatic and TC to RA 032DS85002-2331 F77A-4A376-BB N/A Not Available
manual trans All WB
1995-97 RANGER
1310 Series All W.B., Automatic & TC to FA 918490-1827 F37A-4A376-CB 30.750 Not Available
Manual Trans 2.3L, 3.0L F37A-4A376-C
1310 Series All W.B., Automatic & TC to FA 918490-1717 F37A-4A376-BB 29.406 Not Available
Manual Trans 4.0L F37A-4A376-B
1310 Series All W.B., All Trans TC to RA 919220-2715 F57A-4602-AC 40.500 Not Available
All Engines
1993-94 RANGER
1310 Series Short W.B., 4-Spd. Auto. TC to FA 918490-1827 F37A-4A376-CB 30.750 Not Available
5-Spd. Manual, 2.3L, 3.0L, 4.0L
1310 Series Short W.B., 4-Spd. Auto.,
TC to RA 915983-2812 F37A-4602-PA 40.540 Not Available
5-Spd. Manual, 2.3L, 3.0L, 4.0L
1310 Series Short W.B., 4-Spd. Auto.,
TC to FA 918490-1717 F37A-4A376-BB 29.440 Not Available
5-Spd. Manual, 4.0L F37A-4A376-B
1310 Series Long W.B., 4-Spd. Auto., TC to FA 918490-1827 F37A-4A376-CB 30.750 Not Available
5-Spd. Manual, 2.3L, 3.0L F37Z-4A376-C
1310 Series Long W.B., 4-Spd. Auto., TC to FA 918490-1717 F37A-4A376-BB 29.440 Not Available
4-Spd. Automatic, 5-Spd. Manual, 4.0L F37A-4A376-B
1310 Series Super Cab, 4-Spd. Auto., TC to FA 918490-1827 F37A-4A376-CB 30.750 Not Available
5 Spd. Manual, 2.3L, 3.0L F37Z-4A376-C
1310 Series Super Cab, 4-Spd. Auto., TC to FA 918490-1717 F37A-4A376-BB 29.440 Not Available
5 Spd. Manual, 4.0L F37A-4A376-B
1990-92 RANGER
1310 Series Short W.B, 4-Spd. Auto., TC to FA 918490-1717 F37A-4A376-BB 29.440 Not Available
5-Spd. Manual, 2.3L, 2.9L, 4.0L F37A-4A376-B
1310 Series Short W.B, 4-Spd. Auto., TC to RA 915983-2812 F07A-4602-CA 40.540 Not Available
5-Spd. Manual, 2.3L, 2.9L, 4.0L
1310 Series Long W.B., 4-Spd. Auto.,
TC to FA 918490-1717 F37A-4A376-BB 29.440 Not Available
5-Spd. Manual w/O.D., 2.3L, 2.9L, 4.0L F37A-4A376-B
1310 Series Super Cab, 4-Spd. Auto., TC to FA 918490-1717 F37A-4A376-BB 29.440 Not Available
4-Spd. Automatic, 5-Spd. Manual F37A-4A376-B
w/O.D., 2.3L, 2.9L, 4.0L
