11
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
FORD (Continued)
1990-93 BRONCO
1330 Series, Automatic TC to RA 915841-1506 E9TA-4602-PB 28.290 Not Available
Overdrive Trans. (AOD), 5.0L E9TZ-4602-AD
Eng., 3.55 or 4.10 Axle Ratios
1330 Series, C6 Auto Trans. or Borg
TC to RA 915841-1606 E9TA-4602-MB 29.290 Not Available
Warner T-18 Manual 4-Spd. Wide E9TZ-4602-AB
Ratio, 4.9L(92-90) & 5.0L Eng. w/3.08
or 3.55 Axle Ratio
1987-89 BRONCO
1330 Series, C6 Automatic TC to RA 912637-1617 E7TA-4602-SA 29.630 Not Available
Trans., 4.9L & 5.8L E.F.I Eng. E7TZ-4602-B
w/3.08 & 3.55 Axle Ratios
1330 Series All w/5.0L E.F.I
TC to RA 912637-1517 E7TZ-4602-A 28.630 Not Available
Eng. w/3.08 & 3.55 Axle Ratios E7TA-4602-UA
1330 Series, Manual 5-Spd. w/O.D. TC to RA 912637-1313 E8TA-4602-NA 26.510 Not Available
mazda RZ and ZF H.D. 5-sd. w/O.D. E8TZ-4602-U
Wide Ratio Transmissions, 4.9L & 5.0L
E.F.I Eng. w/3.08, 3.55, 4.10 Axle Ratios
1987 BRONCO
1330 Series, C6 Automatic and New TC to RA 912637-1718 E7TA-4602-TA 30.660 Not Available
Process 435 Manual Trans. 5.0L &
5.8L Eng. W/3.50 Axle Ratio
1330 Series, All w/4.9L Eng. and 5.0L
TC to RA 912637-1617 E7TA-4602-SA 29.630 Not Available
Eng. w/Automatic Overdrive Trans. E7TZ-4602-B
1986 BRONCO
1330 Series, Automatic O.D. Trans., TC to RA 912637-1609 E5TZ-4602-M 29.380 Not Available
5.0 E.F.I. Eng. w/3.55 Axle Ratio
1330 Series, C6 Auto. & Man. 4-Spd.
TC to RA 912637-1806 E5TZ-4602-K 31.290 Not Available
Trans. 5.0L E.F.I. & 5.8L Eng. w/3.50 Axle Ratio
1330 Series, All w/4.9L Eng. and 5.0L
TC to RA 912637-1705 E5TZ-4602-L 30.260 Not Available
E.F.I. Eng. with 4.11 Axle Ratio
1985 BRONCO
1330 Series, Automatic O.D. TC to RA 912637-1609 E5TZ-4602-M 29.380 Not Available
Trans., 5.0L eng. w/3.55 Axle Ratio
1330 Series, Manual 4-Spd. Trans.,
TC to RA 912637-1806 E5TZ-4602-K 31.290 Not Available
4.9L Eng. w/3.00 & 3.50 Axle Ratios,
All 5.0L & 5.8L Eng. w/3.50 Axle Ratios
1330 Series, All 4.9L Eng. w/3.55 &
TC to RA 912637-1705 E5TZ-4602-L 30.260 Not Available
3.08 Axle Ratios, also Automatic O.D.
Trans., 5.0L Eng. w/4.11 Rear Axle Ratio
1983-84 BRONCO
1330 Series TC to RA 910719-1709 E3TZ-4602-AF 30.094 911818-2600 17.281
1980-82 BRONCO
1330 Series TC to RA 910719-1723 E0TZ-4602-AP 30.351 911818-2600 17.719
1979 BRONCO
1330 Series, Part Time Transfer TC to FA 910721-1228 D9TZ-4602-AP 24.344 Not Available
Case, 351 Eng. w/ Manual Trans.
1330 Series, Part Time Transfer
TC to RA 910719-2420 D9TZ-4602-AK 37.281 911818-2600 24.625
Case, 351 Eng. w/ Manual Trans.
1330 Series, Part Time Transfer Case
TC to FA 910729-1531 D9TZ-4602-BS 27.281 Not Available
351 Eng. w/ Automatic Transmission
1330 Series, Part Time Trans. Case,
TC to RA 910719-2121 D9TZ-4602-AL 34-313 911818-2600 21.656
351 Eng. w/ Automatic Transmission
1330 Series, Full Time Trans. Case,
TC to FA 910721-1820 D9TZ-4602-U 30.094 Not Available
351 Eng. w/ Automatic Transmission
1330 Series, Full Time Trans. Case,
TC to RA 910719-1521 D9TZ-4602-AM 28.313 911818-2600 15.656
351 Eng. w/ Automatic Transmission
