22
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
JEEP Short W.B. (Continued)
1979 CJ-7
1310 Series, Automatic Trans. TC to FA 915723-2426 5359382 36.563 909364-2600 24.813
1978 WAGONEER, J10, J20
1310 Series, 6 Cyl., Hydramatic TC to FA 915723-1708 5356506 29.000 909364-2600 17.25
Trans. 5352119
1310 Series, 4-Spd. Trans, V-8 TC to FA 915723-1308 5358684 25.000 909364-2600 13.25
w/ Hydramatic Trans.
1978 CJ-7
1310 Series w/Automatic Transmission TC to FA 915723-2426 5355573 36.563 909364-2600 24.813
5359382
1976-77 CJ-7
1310 Series TC to FA 915723-2426 535573 36.563 909364-2600 24.813
1974-77 CHEROKEE, WAGONEER, J10, J20
1310 Series, 6 Cyl. & V-8, 3-Spd. . TC to FA 915723-0808 5359383 20.000 909364-2600 8.25
Trans 5356503
1310 Series, 6 Cyl. & V-8, 4-Spd. Trans., TC to FA 915723-1221 5356505 24.406 909364-2600 12.656
V-8 Hydramatic Trans., Quadratrac
J10, J20
1310 Series, 6 Cyl., Hydramatic TC to FA 915723-1708 5352119 29.000 909364-2600 17.25
Trans, Quadratrac 5356506
1973 J10. J20
1310 Series, V6, Automatic Trans. TC to FA 915723-1924 5351017 31.500 909364-2600 19.75
1972-73 J10, J20
1310 Series, V-8, Automatic Trans. TC to FA 915723-1516 5351018 27.250 909364-2600 15.5
1971-73 J10, J20
1310 Series, 350 V-8 Eng., TC to FA 915723-1324 5351019 25.500 909364-2600 13.75
4-Spd. Automatic Trans.
PONTIAC
1988 6000 STE
1210 Series, All Wheel Drive, Full Time TC to RA 913797 — — — —
Trans. Case, Two piece rear shaft is
supplied by GM, has Ball Style C.V. Joint
at Trans. Case, a Single Cardan Joint at
the Rear Axle, and a Spicer Double Cardan
Head Assy. at Rear of Coupling Shaft
