CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
HOW TO USE THIS CATALOG
To determine replacement driveshaft by Application you may need to know:
1. Make, model and year of vehicle
2. Manual or Automatic transmission, with or without overdrive
3. 3, 4 or 5 speed transmission
4. Engine size and type (diesel or gasoline-4, 6 or 8 cyl)
5. Axle Ratio
6. Series of driveshaft
7. Wheel base of vehicle
8. Location of Driveshaft (front or rear)
To locate applications in this catalog:
Œ
Locate proper make of vehicle

Locate proper year of vehicle
Ž
Locate proper model of vehicle

Match application in catalog with application data gathered concerning vehicle

Determine if it is a front shaft (TC to FA) or a rear shaft (TC to RA)
‘
Locate part number of Spicer Welded Assembly
’
A finished assembly can be built by using the part number for a Spicer Unwelded Assembly (if shown)
“
Tube length for Unwelded Assemblies
OR
If all of the above has been accomplished and the customer only needs a component replaced, refer to the Bill of
Material Table starting on page 28 of this catalog.
CAUTION! The items in this catalog are listed for use only in those applications for which they were
originally designed and approved. Any other use could result in property damage or serious personal
injury. Do not use the items in this catalog except as replacement parts in the "factory stock" vehicles
for which they were originally designed.
CHEVROLET — GMC
1980 BLAZER, JIMMY
K10, K15, K20, K25
1310 Series, Part Time 205 T.C., TC to FA 912170-1207 Not Available 23.938 913971-2600 12.219
Manual and Turbo Hydramatic 350
Trans, w/30T Involute Spline
K20, K25
1310 Series, Part Time 205 T.C., TC to FA 912170-1511 Not Available 27.156 913971-2600 15.344
Turbo ‘Hydramatic 400 Trans. w/30T
Involute Spline
2
3
5 6 7 8
1
4
