21
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
JEEP Short W.B. (Continued)
1990-94 CHEROKEE, COMANCHE, AND WAGONEER
1310 Series, 2.5L Engine, Auto. Trans., TC to FA 915723-1607 53005540 27.970 Not Available
231 T/C, Model 30 Dana Front Axle
1310 Series, 2.1L & 2.5L Eng. Aisen,
TC to FA 915723-1318 53005541 25.310 Not Available
Man. 5-Spd., 231 T/C, Model 30 Dana Axle
1310 Series, 4.0L Eng. Aisen Warner,
TC to FA 915374-1903 53005542 30.660 Not Available
4-Spd. Auto, 231 T/C & 242 T/C,
Model 30 Dana Front Axle
1310 Series, 4.0L Eng. Aisen
TC to FA 915374-1722 53005543 29.250 Not Available
Seiki, Man. 5-Spd., 231/Kanda
T/C, Model 30 Dana Axle
1310 Series, 4.0L Eng. Aisen
TC to FA 915374-1517 53005544 27.080 Not Available
Seiki, Man. 5-Spd., Kanda
T/C, Model 44 Dana Axle
1310 Series, 4.0L Eng. Aisen
TC to FA 915374-1702 53005545 28.620 Not Available
Warner, Auto. 4-Spd., Kanda
T/C, Model 44 Dana Axle
1990-91 SENIOR JEEP (GRAND WAGONEER)
1310 Series, 5.9L Eng., 727 Auto. TC to FA 915724-1427 53005539 25.700 Not Available
Trans., 229 T/C, Model 44 Dana Axle
1988 CHEROKEE, COMANCHE, AND WAGONEER
1310 Series, 6 Cyl. Eng. Peugeot, TC to FA 915723-1607 8953003912 27.953 909364-2600 16.219
Automatic Trans., Kanda P.t. Trans.
Case, 4.11 Axle Ratio
1310 Series, 4 Cyl. Eng. Aisen, 4 &
TC to FA 915723-1318 8953003235 25.313 909364-2600 13.563
5-Spd. Manual Trans., 3.55 & 4.11
Axle Ratios, 231 Transfer Case
1310 Series, 6 Cyl. Eng., Auto. Trans.,
TC to FA 915374-1903 8953005040 30.672 Not Available
242/231 Trans. Cases, 3.55 Axle Ratio
1310 Series, 6 Cyl. Eng. Peugeot,
TC to FA 915374-1722 8953005039 29.250 Not Available
Automatic Trans., 242/231 Trans,
Cases, 3.08 Axle Ratio
1982-83 CHEROKEE, WAGONEER, J10
1310 Series, 6 Cyl. w/5-Spd. TC to FA 915724-1714 5363399 28.969 Not Available
1982-83 CJ10
1310 Series, Automatic Trans. TC to FA 915724-1921 5994167 31.188 Not Available
1310 Series, Manual Trans. TC to FA 915724-1620 5994166 28.188 Not Available
1980-83 CHEROKEE, WAGONEER, J10
1310 Series, 6 Cyl., Automatic TC to FA 911334-1721 5360997 29.188 Not Available
1310 Series, 6 Cyl. & V-8, TC to FA 915724-1427 5360995 26.375 Not Available
4-Spd. Man. Trans.
1980-83 J20
Trans. 915724-1721
1310 Series, V-8, Automatic Trans. TC to FA 915724-1405 5360996 25.688 Not Available
1310 Series, 6 Cyl. & V-8, TC to FA 915724-2328 5360998 35.406 Not Available
4-Spd. Trans., 131" Wheel Base
1979 WAGONEER, J10, J20
1310 Series, 6 Cyl., 3-Spd. Trans. TC to FA 915723-0908 5359384 21.000 909364-2600 9.25
1310 Series, V-8, 3-Spd. Trans. TC to FA 915723-0808 5359383 20.000 909364-2600 8.25
1310 Series, 6 Cyl., Hydramatic Trans. TC to FA 915723-1708 5359385 29.000 909364-2600 17.25
1310 Series, 4-Spd. Trans., TC to FA 915723-1308 5359386 25.000 909364-2600 13.25
V-8, Hydramatic Trans.
