Spicer Double Cardan Constant Velocity Joint Assemblies - Manual (Page 11)

12
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
FORD (Continued)
1978 BRONCO
1310 Series, Part Time 205 Trans. TC to FA 906638-1226 D8TZ-4602-R 24.344 909363-2600 11.188
Case, 351 & 400 Eng. w/Manual
Trans., 3.50 & 4.11 Axle Ratio
1310 Series, Part Time 205 Trans.
TC to RA 910255-2405 D8TZ-4602-H 37.313 909363-2600 24.156
Case, 351 & 400 Eng. w/Manual
Trans., 3.50 & 4.11 Axle Ratio
1310 Series, Part Time 205 Trans.
TC to FA 909762-1529 D8TZ-4602-L 27.281 Not Available
Case, 351 Eng. w/AutomaticTrans.,
3.00 Axle Ratio
1310 Series, Part Time 205 Trans.
TC to RA 910255-2107 D8TZ-4602-K 34.375 909363-2600 21.219
Case, 351 Eng. w/AutomaticTrans.,
3.00 Axle Ratio
1310 Series, Full Time 203 Trans.
TC to FA 906638-1818 D8TZ-4602-S 30.094 909363-2600 16.938
Case, 351 Eng. w/Automatic Trans.
& 3.00 Axle Ratio
1310 Series, Full Time 203 Trans.
TC to RA 910255-1507 D8TZ-4602-J 29.375 909363-2600 15.219
Case, 351 Eng. w/
Automatic Trans. & 3.00 Axle Ratio
1310-1330 Series, Part Time 205
TC to FA 910539-1531 D8TZ-4602-T 27.281 Not Available
Trans. Case, 400 Eng. w/Automatic
Trans. and 3.00 Axle Ratio
1310-1330 Series, Full Time 203
TC to FA 910424-1820 D8TZ-4602-U 30.094 Not Available
Trans. Case, 400 Eng. w/Automatic
Trans. and 3.00 Axle Ratio
1974-77 BRONCO
1310 Series, All Trans. Cases, 302 TC to FA 904084-1023 D1TZ-4602-G 22.250 909363-2600 90.94
Eng. w/ Automatic or Manual Trans.
1310 Series, All Transfer Cases, 302
TC to RA 907545-1802 C9TZ-4602-W 31.219 909363-2600 18.063
Eng. w/ Auto. or Manual Transmission
1971-73 BRONCO
1310 Series TC to FA 904084-1023 D1TZ-4602-G 22.250 909363-2600 9.094
1310 Series TC to RA 907545-1802 C9TZ-4602-W 31.219 909363-2600 18.063
1966-70 BRONCO
1310 Series, after Serial # 670,000 TC to FA 904084-1125 C9TZ-4602-V 23.313 909363-2600 10.156
1310 Series, after Serial # 670,000 TC to RA 907545-1802 C9TZ-4602-W 31.219 909363-2600 18.063
1310 Series, before Serial #670,000 TC to FA 905026-1125 C9TZ-4602-Z 23.313 909363-2600 10.156
with Mechanics 2RL Joints
1310 Series, before Serial #670,000
TC to RA 905027-1802 C9TZ-4602-AA 31.219 909363-2600 18.063
with Mechanics 2RL Joints
1989-90 BRONCO II
1210 Series, 4-Spd. Auto., 5-Spd. Man., 2.9L TC to RA 914778-1013 Not Available 25.850 Not Available
1210 Series, 4-Spd. Automatic, 2.9L TC to RA 914155-1906 Not Available 32.200 919976-3400 19.56
Dbl. Cardan at Tran
1210 Series, 5-Spd. Manual, 2.9L
TC to RA 914155-2217 Not Available 35.540 919976-3400 22.91
Dbl. Cardan at Tran
1988 BRONCO II
1210 Series, 4-Spd. Automatic, TC to RA 914778-1013 Not Available 25.850 Not Available
5-Spd. Manual, 2.9L
1986-87 BRONCO II
1210 Series, 5-Spd. Manual/O.D., TC to RA 914155-1522 Not Available 28.690 919976-3400 16.06
w2.3L, 2.9L, 2.3D
Dbl. Cardan at Trans. Case End
1985-87 BRONCO II
1210 Series, 4-Spd. Auto., 2.8L, 2.9L TC to RA 914778-1013 Not Available 25.850 Not Available
