Spicer Double Cardan Constant Velocity Joint Assemblies - Manual (Page 23)

24
SOCKET YOKE ASSEMBLY DIMENSIONAL DATA
211489X = 1210 1 3.50 2.468 2.468 .484 2.000 1.625 .500
211543X < ‡ 1310 1 3.50 2.484 2.484 .484 2.000 1.625 .500
211229X <4 1310 1 3.50 2.484 2.484 .484 2.000 1.625 .500
211452X = 1310 1 4.25 3.000 3.000 .453 3.125 1.625 .500
211198X = 1310 1 4.00 2.937 2.937 .453 3.125 1.625 .500
211545X < 1310 1 4.25 3.000 3.000 .453 3.125 1.625 .500
212040X 1310 1 4.25 3.00 3.00 .488 3.126 1.620 .500
211631X < 1330 1 4.25 3.000 3.000 M12X1.75th’d 2.000 1.625 .500
211913X < 1330 1 4.25 3.000 3.000 .462 3.125 1.625 .500
211889X = 1330 2 4.00 2.953 2.656 .453 3.125 1.875 .500
211606X 1330 2 4.00 2.953 2.656 .453 3.125 1.812 .500
211520X = 1330 2 4.00 2.953 2.656 .453 3.125 1.875 .625
211868X = 1330 2 4.25 3.000 3.000 .453 3.125 1.812 .500
212025X < 1350 1 4.25 3.000 3.000 M12X1.75th’d 2.680 1.625 .500
212024X < 1350 1 4.25 3.000 3.000 M12X1.75th’d 2.000 1.625 .500
211519X 1210 — 2.437 1.500 2.343 .250-28th’d 1.640 has .500 stud
211342X 1210 3 2.437 1.500 2.343 .250-28th’d 1.531 .500
211544X < 1310 3 3.218 1.500 2.343 .312-24th’d 1.656 .500
211355X 1310 3 3.218 1.500 2.343 .312-24th’d 1.531 .500
210841X 1330 3 3.625 1.500 2.875 .312-24th’d 1.562 .625
211179X = 1330 3 3.625 1.500 2.875 .312-24th’d 1.562 .500
211996X < ‡ 1330 3 3.625 1.500 2.875 .312-24th’d 1.690 .500
212019X < 1350 3 3.625 1.625 2.750 .312-24th’d 1.757 .500
Bolt Holes Dimension Fits
Ball Stud
A B C D E Size
Bolt Holes Dimension Fits
Socket C/L To End Ball Stud
Yoke Assembly Series Style K A B C E Size
FOOTNOTES: = Flush Zerk (#230977) 4 Socket OD 1.394
< Non-Greasable ‡ Socket OD 1.625
Dia. Dia.
Pilot
Dia.
Pilot
Dia.
Thread
Style 3
Style 1
Style 2
Flanged Socket Bolt Circle
Yoke Assembly Series Style Diameter
