14
TC to FA — Transfer Case to Front Axle
TC to RA — Transfer Case to Rear Axle
CENTERLINE SPICER UNWELDED
SPICER TO ASSEMBLY
WELDED CENTERLINE
YEAR/MAKE/MODEL LOCATION ASSEMBLY OEM NUMBER OF CROSS PART TUBE
DESCRIPTION NUMBER (Collapsed NUMBER LENGTH
Lengths) REQUIRED
FORD (Continued)
1977 F150
1310 Series, Part Time Transfer Case, TC to RA 907758-3621 D7TZ-4602-J 50.938 Not Available
351, 400 Eng. with C6 Trans. and 116"
Wheel Base before Serial # Y80,001
1310-1330 Series, Part Time Transfer
TC to RA 910413-3806 D8TZ-4602-D 50.938 Not Available
Case, 351, 400 Eng. with C6 Trans
and 116" Wheel Base after Serial # Y80,001
1310 Series, Full Time Transfer Case
TC to FA 904084-1908 D4TZ-4602-M 30.781 909363-2600 17.625
w/116" & 133" Wheel Base before
Serial # Y80,001
1976 F150
1310 Series, Manual Trans., TC to RA 907758-3703 D6TZ-4602-E 51.375 Not Available
with 116.8" Wheel Base
1999-2000 F250HD
1350 Series,5.4L engine w/ E4OD TC to RA 921007-3702 F81Z-4602-DG 50.875 Not Available
Auto Trans,and 137" WB
1350 Series,5.4L engine w/ M5HD
TC to RA 921007-4016 F81Z-4602-DH 54.290 Not Available
Man. Trans, and 137" WB
1350-1410 Series,6.8L engine w/ E4OD TC to RA
920575-3708 F81Z-4602-CC 50.790 Not Available
Auto Trans, and 137" WB
1350-1410 Series,6.8L engine w/ M5HD TC to RA
920575-4024 F81Z-4602-DC 54.290 Not Available
Man. Trans, and 137" WB
1350-1410 Series,7.3L engine w/ E4OD TC to RA
920575-3413 F81Z-4602-CN 49.57 Not Available
Auto Trans, and 137" WB
1350-1410 Series,7.3L engine w/ M5HD TC to RA
920575-3616 F81Z-4602-DA 51.66 Not Available
Man. Trans, and 137" WB
1350 Series,5.4L engine w/ E4OD
TC to RA 921007-4127 F81Z-4602-DK 57.25 Not Available
Auto Trans, and 141.8" WB
1350-1410 Series,5.4L engine w/ M5HD TC to RA
920575-4512 F81Z-4602-DL 60.54 Not Available
Man. Trans, and 141.8" WB
1350-1410 Series,6.8L engine w/ E4OD TC to RA
920575-4203 F81Z-4602-DM 57.25 Not Available
Auto Trans, and 141.8" WB
1350-1410 Series,6.8L engine w/ M5HD TC to RA
920575-4520 F81Z-4602-DN 60.79 Not Available
Man. Trans, and 141.8" WB
1350-1410 Series,7.3L engine w/ E4OD TC to RA
920575-3909 F81Z-4602-DQ 54.45 Not Available
Auto Trans, and 141.8" WB
1350-1410 Series,7.3L engine w/ M5HD TC to RA
920575-3909 F81Z-4602-DQ 54.45 Not Available
Man. Trans, and 141.8" WB
1979 F250
1330 Series, Part Time Transfer TC to FA 910721-1320 D9TZ-4602-V 25.094 Not Available
Case, 300 Eng. w/Manual Trans.
& 133" Wheel Base
1978 F250
1310-1330 Series, Part Time 205 TC to FA 910424-1320 D7TZ-4602-AG 25.094 Not Available
Transfer Case w/Manual Trans. and
133" Wheel Base
1310-1330 Series, Part Time 205
TC to FA 910424-1618 D7TZ-4602-AJ 28.031 Not Available
Transfer Case w/Automatic Trans.
and 133" Wheel Base
1310-1330 Series, Full Time 203
TC to FA 910424-1911 D7TZ-4602-AH 30.813 Not Available
Transfer Case w/Automatic Trans.
and 133" Wheel Base
F250 WITH SNOW PLOW OPTION
1310-1330 Series, Part Time TC to FA 910424-1909 D8TZ-4602-AL 23.750 Not Available
205 Transfer Case with Manual
Trans. and 133" Wheel Base
