50

8.4 Data Selection

The Data Selection area of the Record Setup Interface displays a summary of the options selected by
the user. It also displays some relevant data size information.

The

button launches the Record Data Selection interface that defines:

Data Recording Mode (see section 8.4.1, p. 50)

Data Record Rate (see section 8.4.2, p. 54)

Values to Record (see section 8.4.3, p. 54)

8.4.1

Instantaneous / Average Record Mode

The

switch defines the record mode.

Instantaneous / Average

Record Mode

Data Selection Options

Sampling Rate

Data Selections
