33

7.2.6

Vibration Historic Graph

Available data

Data Type

Input

Display Parameter

Freq Weighting

Vibration Global

level

X, Y, Z or

SUM XYZ

Instant

For details, see the section 6.2.6, p.24

Average

Length of the historic graph

During the acquisition, the historic only displays the last few samples. The time span is adjusted to
match the SLM historic graph. Past samples may be displayed once the acquisition has been stopped
(see section 5.5.3.1, p. 16).
