7

Before

Measurement

During

Measurement

After

Measurement

Run / Pause / Continue Button

Stop / Save Button

← Current DataSet

← Previous / Next DataSet

← Next DataSet To Be Saved1

← Leq Averaging Time

← Running Time

← Current Leq Period Time

← Current Dataset Time

← Time from Start

Over / Under Range Indicator

Audio Recording Indicator

Photo Information Indicator

FTP Information Indicator

1

This indicator flashes red for 10 seconds when the measurement has stopped but has not been saved.
