13

5.4 Menu Bar

File Menu

Open DataSet

Opens a DataSet.

Save DataSet

Saves a DataSet if not saved yet.

Export DataSet

Exports DataSets in a spreadsheet file.
(see section 0, p. 65)

File Manager

Launches the File Manager
(see section 0, p. 66)

Open Config

Restores a saved software configuration.

Save Config

Saves the software configuration.

Quit:

Quits the SLM module and to returns to
the Opus Suite Interface.

Input / Display / Record Setup Buttons

Launches the Input Setup (see section6, p. 18)

Launches the Display Setup (see section 7, p. 25)

Launches the Record Setup (see section 8, p.41)

Comment / Tag Button

Allows the user to write a comment on the measurement before it starts. When
the measurement starts, this button becomes the Tag button.

Tags events during a measurement.
