5 Main Interface

The main interface is divided in five areas:

1)

Measure controls (see section 5.1, p. 10)

2)

File Info (see section 5.2, p. 10)

3)

Measure Info (see section5.3, p. 12)

4)

Menu bar (see section 5.4, p. 12)

5)

Display area (see section 5.5, p. 14)

On the main interface, the following actions are possible:

Perform a measurement according to the current measurement setup,

Save, Export and Open DataSets using the

menu,

Modify the setup using the

,

and

menu (see next table).

Display area

Menu bar

Measure controls

File

info

Measure

info
