Vib 1/3 Octave Spectrum Graph
Available data
Data Type
Input
Display Parameter
Freq Weighting
Vib 1/3 Octave
Spectrum
X, Y, Z or SUM XYZ
Instant
For details, see the section
Average
Legend Values
Selecting
versus
on a 1/3 Octave Band Spectrum graph displays either the Global
value or the Band value (associated to the cursor) on the Legend (see section 5.5.3.1, p. 16).
