Ohaus AP250E ANALYTICAL Plus Electronic Balances - Manual (Page 70)

70
MODEL MODEL MODEL MODEL MODEL AP110 AP110 AP110 AP110 AP110 AP210 AP210 AP210 AP210 AP210 AP310 AP310 AP310 AP310 AP310 AP250D AP250D AP250D AP250D AP250D
Capacity (g) 110 210 310 52/210
Readability (mg) 0.1 0.01/0.1
Weighing modes g, oz, ct, dwt, (3) taels, oz t, gn, mommes,
1 custom unit, parts counting, percent weighing,
Repeatability (Std. dev.) (mg) 0.1 0.2 0.02/0.1
Linearity (mg) ±0.2 ±0.5 ±0.03/0.2
Tare range To capacity by subtraction
Stabilization time (sec) 4 8 12/5
Sensitivity drift (10 - 30 °C) ±2 ppm/ °C
Operating temperature range 50° to 104°F/10° to 40°C
Calibration Motorized internal and manual external
Internal calibration weights Stainless steel - measured to ±0.1 mg at an
air density of 1.2 mg/cm 3
on virtual mass with density 8.0 g/cm 3
Power requirements 100, 120, 220, 240 V ac, 50/60Hz
Display (in/cm) Vacuum fluorescent (0.5/1.3 high)
Pan size (in/cm) 3.5/9
Free height above pan (in/cm) 9.5/24
Dimensions 7.7 x 12.2 x 15.7
(WxHxD) (in/cm) 19.5 x 31 x 40
Net weight (lb/kg) 22.5/10.2
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
MAINTENANCE
