6.4
Technical specifications and illustrations are without
obligation, subject to modifications. 10.08
* Standard, other version on request.
** Option
*** Maximum values in technical data’s must be rated in consideration of total cooling capacity at 25 °C ambient temperature..
2) With GL-Connecting adapter.
3) With SR25.2 max. 2 bar abs.
GL adapter and tube fittings for the connection of differerent tube diameters at the heat exchanger see chapter 11, data sheet 11.5 and 11.6.
Technical Data
Order example:
1 cooler EC-L with 2 heat exchangers out of glass ECL-G and 2 peristaltic pumps SR25.2, power 115V 60Hz:
Part. No. 1x 02K4000Xa; 2x 97K0605; 2x 01P9125
Gas cooler series EC ® version EC-L
Part No. for basis cooler without heat exchanger,
230V 50Hz 02K4000X
Part No. for basis cooler without heat exchanger,
115V 50-60Hz 02K4000Xa
Number of heat exchangers 2
Ambient temperature +10 up to +45 °C
Sample outlet dew point range of adjustment: +2 °C ..... +7 °C, factory setting: +5 °C
Dew point stability at constant conditions < ±0,1 °C
Sample inlet temperature*** max. 180 °C
Sample inlet dew point*** max. 80 °C
Total cooling capacity 144 KJ/h at +10 up +45 °C ambient
Ready for operation <15 min.
Main power connection / power consumption 230V AC* or 115V AC**(a) -15%/+10%, 50/60 Hz, max. 200VA
start up current: 230V 50Hz = 2,5A / 115V 60Hz = 4,5A
Electrical connection terminals 2,5mm 2 , 2x PG11 cable gland (with FM-approval conduit-hub 1/2” NPT)
Status alarm-2 contacts, potential free contact rating 250VAC, 2A, 500VA, 50W, alarm point <+2 °C and >+8 °C*
Case protection / Electrical standard IP20 EN60529 / EN 61010
UL
in preparation:
Class I, Div.2, Group A, B, C, D, T4
Method of mounting / Case colour wall mounting / case colour grey, RAL 9003
Dimension / Weight 210x311,5x300 mm (w x h x d) / 17,6 kg (with 2 SR25.2 and 2 glass heat exchangers)
Options for basis cooler EC-L
Heat exchanger type ECL-G ECL-PV ECL-SS
Part No. 97K0605 97K0610 97K0600
Material of heat exchanger Duran glass PVDF st. steel 316Ti
Max. gas flow rate per h.e. 250 Nl/hr*** 250 Nl/hr*** 250 Nl/hr***
Gas press. max. bar abs.
3)
2 / 3 2) 3 10*
Sample gas connection GL18 for ø 6 mm o.d. tube* Tube ø 6 mm* Tube ø 6 mm
Condensate connection GL25 for
ø 12 mm tube*
ø 8 mm
or ø 10 mm** G3/8’’i G3/8’’i or
3/8 NPT**
∆P at max. flow rate 1 mbar 1 mbar 1 mbar
Stagnant space approximately 50 ml ml ml
Peristaltic pump SR25.2 1 pc. incorporated in the cooler, compl. installed, Part No.: 01P9125 cooler weight plus 0,6 kg per pump
One ambient pre-cooling stage, completely
installed
Two ambient pre-cooling stages, completely
installed
One peristaltic pump for a pre-cooling stage including mounting plate, completely installed, Part No.:
Two peristaltic pumps for a pre-cooling stage including mounting plate, completely installed, Part No.:
Mounting plate for gas conditioning components like filter or pump, completely installed, Part No.:
Filter FP-2T-D with liquid alarm sensor LA1S, completely installed on the mounting plate, Part No.:
Diaphragm pump, completely installed on the mounting plate, Part No.:
Analog output for cooler temperature, Part No.:
Options
