Technical Data
*For diaphragm pumps version (N.. KP18) with housing in 115V please specify in your order: power 115V and add an “a” to the part number.
Pump series N N3 KPE / N3 KP18 N5 KPE / N5 KP18 N9 KPE / N9 KP18
Part number* 02P3351 / 02P3006 (a)* 02P3355 / 02P3007 (a)* 02P3360 / 02P3008 (a)*
Housing version NO / YES
Capacity max. at atmospheric pressure 3 Nl/min 5 Nl/min 8,5 Nl/min
Max. operating pressure 0,25 to 1,95 bar abs 0,15 to 2,7 bar abs. 0,15 to 1,5 bar abs.
Sample and ambient temperature +5 up to +40 °C
Storage temperature -15 up to +60 °C
Operation mode continuous
Power supply
with link at terminal changeable 230V 50Hz, 0,75A or
115V 60Hz, 1,5A 60W 230V 50Hz, 0,65A or
115V 60Hz, 1,2A 60W
Electrical connection KPE: wire 4 x 0,5mm
2
, approx. 900 mm long
KP18: Cold appliance plug with 2 fuses 230V - 1A / 115v - 3,2A 2,5 m of cable and power switch
Protector Thermo switch, double (115V/230V)
Protection ... KPE: IP00 EN 60529
... KP18: IP20 EN 60529
Weight ... KPE: 1,1 kg
... KP18: 1,9 kg ... KPE: 1,3 kg
... KP18: 2,1 kg
Gas connections G1/8”i DIN ISO 228/1
Material of parts in contact with the sample pump head: PVDF, diaphragm: PTFE, valves / sealing: VITON
Housing material ... KP18 AL-Mg-Si-0,5 / firmness: F25, colour RAL 9002 white-grey
