Technical Data
Version PMA 20 thermostated oxygen analyser in a wall mounting housing
Part No. 02A1000 : PMA 20, power supply 230V 50Hz, signal 0-1V + 0-20mA; 02A1000a=115V 60Hz
Measuring ranges selectable for 0-3, 0-10, 0-30 and 0-100 vol.% O
2
, linear
Indication
analogue meter with a scale of 0-30 and 0-100% for each selected range
option: combined analogue / digital meter:
analogue meter with a scale of 0-30 and 0-100% for each selected range, digital meter, 3
1 /
2
digit 9 mm high LCD-
indicator for 0-100%O
2
reading, selectivity 0,1vol.% O
2
or digital meter 3
1 /
2
digit 18 mm high LCD for 0-100% O
2
reading, selectivity 0,1 vol.% O
2
, Part No.: 02A9000
Output signals 0-1V DC non-isolated, load > 100 KΩ, for the range of 100 vol.%, and
0-20mA or 4-20mA* for the chosen range, non-isolated, max. load 300Ω
Response time for 90% FSD < 3 seconds at 60 Nl/hr air
Accuracy after calibration deviation: analogue = ± 1% of span / digital = ± 0,1 vol.% O
2
Reproducibility deviation: analogue = < 1% of span / digital = ± 0,1 vol.% O
2
Influence of ambient temperature no influence up to 45 °C
Influence of barometric pressure The oxygen reading varies in direct proportion to changes of the barometric pressure.
Influence of sample gas flow variation in gas flow between 0-60 Nl/hr air will cause a difference of < 0,1 vol.% O
2
Sample gas inlet pressure 0,01 up to 1 bar g, (PMA 20 required admission pressure for competent flow rate, no pump inside)
Sample gas outlet pressure outlet of analyser must discharge freely into atmosphere
Flow rate of sample gas max. 60 Nl/hr air, adjustable with needle valve on the flowmeter 7-70 Nl/hr
Temperature of sample gas -10 °C up to +40 °C dry gas
O
2
-transducer temperature fixed at +50 °C
Ambient temperature -10 °C up to +45 °C
Storage temperature -20 °C up to +60 °C, relative humidity 0-90% RH
Power supply internal power unit for 230V AC standard or 115V AC available (a)* +/-10%, 40-60Hz, 26,5VA
Electrical connections terminals 2,5 mm 2 ; 1x PG11, 1x PG13,5 cable gland
Materials in contact with sample gas Platinum, Glass, Polypropylene, Stainless Steel 316Ti, FPM, Epoxy resin
Sample gas connection PP hose connectors DN 4/6 for 4 mm i.d. and 6 mm o.d. tube
Protection / electrical standard IP 53 EN 60529 / EN 61010
Housing / front colour plastic wall mounting housing / blue/grey
Dimension / weight height 220 mm, width 214 mm, length 182 mm / approx. 3 kg
Certificate option: approved according to DIN EN 14181 resp. to 13th and 17th BImSchV and TA-Luft,
Part no. 02A9010
* Please specify with order.
W A R N I N G ! I M P O R T A N T
An external fine filter must always be used at the gas inlet of the analyser.
Depending on the composition of the sample gas, it may be necessary to use a
sample conditioning system. Without precautions, the analyser is only suitable
for measuring of non-hazardous gases or gasmixtures in non-hazardous areas.
