9.5
Technical specifications and illustrations are without
obligation, subject to modifications. 09.96/11.06
Electronic controller type FA-1.1 FA1.4 K-FA **
Part No.
230V 50/60Hz
115V 50/60Hz
24V
DC
24V
AC
02 E 7300*
02 E 7300*
02 E 7300 d
02 E 7300 b 02 E 7110
02 E 7110 a
02 E 7110 d
02 E 7110 d
02 E 4020
Mounting Wall mounting housing Rail mounting housing
EN 50022 Wall mounting housing
Sensor inlets 1
Function mono-stable / bi-stable / KS 2 all, selectable by assignment mono- or bi-stable selectable
Power consumption 2 VA 1 VA
Alarm-relay (MC/NC/NO)
contact rating 250V DC/AC
AC=500VA, DC=50W, 3A
250V AC/DC
AC=500VA, DC=45W, 2A
Pull-in/drop-off time lag
of alarm relay 2 sec.
Cable entry 1x clamping range 3mm - 6,5mm
2x clamping range 5mm - 10mm 1x clamping range 3mm - 6,5mm
2x clamping range 5mm - 10mm
Electrical connections Terminals max. 2,5 mm 2
Adjustment of sensitivity for
sensor FA.. after removing the lid
at the potentiometer in the front side of the housing at
the potentiometer
Distance between sensor
and electronic FA-.. max. 10m >10m, max. 200m
Line break monitoring yes
Housing protection type IP65 EN 60529 IP20 EN 60529 IP65 EN 60529 IP20
Housing material Polycarbonate Polyamide Polycarbonate
Ambient temperature -25 °C to +60 °C
Electrical standard EN61010
Dimensions B 80 x L 160 x H 55 mm B 22,8 x L 100 x T 111 B 80 x L 160 x H 55 mm
Weight 0,31 kg 0,18 kg 0,3 kg
Technical Data
* Reversing power consumption 230V 50/60Hz / 115V 50/60Hz, adjusted at works: 230V 50/60Hz
** For use in combination with electronic controller FA-1.1 or FA-1.4 if the wiring length between the flow alarm sensor and the electronic controller is more
than 10m
