7
Gas sampling and conditioning technology 5-5.1.1-ME
7 APPLICATION
Liquid alarm sensors LA 1S and LA 25S are used in gas sample conditioning systems for monitoring
gas cooling and condensate drain-off devices in order to provide protection for downstream analysis
instruments. This simple monitoring device reliably signals the penetration of condensate in the event
of cooling or condensate drain-off equipment being defective and thus avoids expensive down times
as well as high repair costs for analysis instruments.
The electronic controllers LA-1.1 and LA-1.4 are used for feeding and signal processing of the liquid
alarm sensors LA 1S and LA 25S.
In the event of alarm, the power for the sample gas pump or a solenoid valve is to be switched off in
the gas sample conditioning system.
8 TECHNICAL DATA
Sensor Series LA ® LA 1S LA 25S
Flow chamber LS LS 25
Part Number 03 E 1001 03 E 3100 03 E 1111 03 E 1120
Connection cable 2 m 2 m
ø 4,2 mm, 2-core each additional meter of connection cable = part No. 03E 9001, total max. 100 meters
Pressure 0 - 4 bar g**** 0 - 25 bar g (up to 100 bar g*)
Flow 0 - 1000 l/h
Operating temperature +80 °C ***
Gas connections ø 12 mm G 1/4" i 1/4" NPT a ø 8 mm **
Stagnant space approx. 3 ml 3 ml
Material of sample
contacting parts ***
glass, platinum
PVDF,
FPM SS316Ti,
PVDF
SS316Ti
Type of mounting clamping attachment wall screw on pipe
Mounting position vertical
Electrical conductivity >50 µS/cm
Weight 50 g 60 g 140 g 100 g
* other pressure ranges -, ** other dimensions -, *** other materials or temperatures on request
**** max. 2 bar when mounted in universal filter
A Electronic controllers type LA-1.1 LA-1.4
Electronic Controller Series LA ® Type LA-1.1 LA-1.4
Part Number
230V 50/60Hz
115V 50/60Hz
24V DC
24V AC
03 E 2001*
03 E 2001*
03 E 2001* d
03 E 2001* b 03 E 2006
03 E 2006 a
03 E 2006 d
03 E 2006 d
Mounting Wall mounting housing Rail mounting housing EN 50022
Sensor inlets 1
Power consumption 2 VA 1VA
Alarm-relay (2x MC/NC/NO)
contact rating 250V DC/AC
DC=50W, AC=500VA, 3A 250V DC/AC
DC=45W, AC=500VA, 2A
Cable inlet 1x terminal range 3mm - 6,5mm
2x terminal range 5mm - 10mm
Electrical connection Terminals max. 2,5 mm 2
Adjustment of switching point Via potentiometer after opening of housing Via potentiometer in the housing front
Distance between sensor and
electronic LA-1.. max. 100m
Line break supervision yes
Alarm reset** yes
Protection type IP65 EN60529 IP20 EN60529
Housing material Polycarbonate Polyamide PA 6.6 combustibility class VO
(UL94)
Ambient temperature -25 °C to +60 °C
Dimensions B 80xL 160xH 55 mm B 22,8 x L 100 x H 111 mm
Weight 0,31 kg 0,23 kg
Reversible distribution voltage 230V 50Hz / 115V 60Hz, at works adjusted to 230V 50Hz.
** at works deactivated
