9.2
Technical specifications and illustrations are without
obligation, subject to modifications. 09.96/11.06
M10x1
max.4 30
37
71
DN4/6
DN4/6
Technical Data
Dimensions
Dimensions in mm
Flowmeter FM 40
Flowmeter FM 40
Measuring-range calibrated at 1 bar abs., 20 °C 7-70 l/hr air, Part No: 09F4000
15-150 l/hr air, Part No: 09F4005
25-250 l/hr air, Part No: 09F4010
50-500 l/hr air, Part No: 09F4015
Measuring range width 10:1
Accuracy class 6 %
Scale calibrated in l/hr
Scale length approx. 30 mm
Pressure max. 3 bar abs.
Temperature max. 60 °C
Connections Tube connectors DN 4/6 mm
Material used for parts in contact with medium PVDF, glass, Hastelloy C4, FPM
