Technical Data
45
15
ø 70
1/2" NPT
G1/4"
185
1/2" NPT
SW 27
SW 27
ADS-SS
*
*
Dimensions in mm
Drain capacity depending on working pressure
Mounting clip AD-SS for wall mounting
Max. working pressure depending on specific gravity
77
20 ш 63
ш 17
17
25 ш 9
84
bar
g/c
m
3
0,4
1,0
0 2,9 6,3 9,6 13 16,3 19,3
0,5
0,6
0,7
0,8
0,9
18,0
max.
Dimensions
Separator ADS-SS
Automatic liquid drain AD-SS
l/h H
2
O
ba
r
0
5
10
15
20
0 225 325 400 460 525 725 160 275 360 430 490 660
*only at version ADS-SS
Liquid drain AD-SS ADS-SS Mounting clip
Part number 09K3000 09K8000 90K3010
Material stainless steel 304, 316 PE
Operating temperature 0 to +200 °C -20 to +90 °C
Storage temperature -50 to +200 °C -30 to +110 °C
Operating pressure 1-19 bar abs.
Function specific gravity min. 0,5 kg/dm 3 , at 1 bar abs.
Capacity 160 l/hr H2O, at 1 bar abs. and 20 °C
Mounting position vertical
Condensate in 1/2" NPT i
Condensate out 1/2" NPT i
Sample gas in G1/4" i
Sample gas out 1/2" NPT i
Weight 0,8 kg 0,05 kg
