Technical Data
Dimensions
Dimensions in mm
Probe Series SP® Portable Version PSP4000 PSP4000-H PSP4000-H /C PSP4000-H /C /T
Part No. 230V
Part No. 115V 40S1000
40S1000a 40S1005
40S1005a 40S1015
40S1015a
Sample temperature max. 600 °C *standard
Sample pressure max. 1 bar
Ambient temperature -20°C to +60°C
Filtration chamber volume 40 cm 3
Filter element S-2K ceramic, 2 µm
Probe temperature adjustable between 100 to 180°C, pre-set at works to 180°C
Ready for operation After approximately 30 minutes
Gas inlet Basic connection G 3/8"i, probe tube or adapters optional
Gas outlet 1/8" NPT + tube connector 6 mm (8 mm optional)
and pipe clamp for attachment of heated sample line
Electrical power supply 220-240V 50/60Hz, 200 W or 115V 60Hz
Electrical connection Plug and socket connector 7 pin with 4 meter connection cable
Electrical equipment standard EN 61010, EN 60335-1
System of protection IP40 EN 60529
Material Stainless steel 316Ti, ceramic, FPM
Weight 3,5 kg
Calibration gas connection for SS-tube/Plastic hose ø 6 mm no yes yes
Temperature measurement with Thermocouple sensor FeCuNi,
length 600 mm with 4 m connection cable and standard plug. no no yes
530
300
Aluminium
PSP4000-H
420
