2.17
Technical specifications and illustrations are without
obligation, subject to modifications. 09.96/03.09
DImensions
Dimensions in mm
M&C Probe
Prefilters
Type
Part-No.
Temp.
max.
°C
Material
Filter / Connection
Filter
porosity
micron
Dust
content
g/m
3
Inside
volume
displacer
Back-
purging
Length
„L1“
mm
Filter
ø „d1“
mm
Connection
„G“
SP2000/20SS 150
20S9160
600
stainl. steel 316/316Ti
20
2-10
yes
150
31
ø 25
SP2000/V20
20S9085
600
stainl. steel 316/316Ti
2
2-10
yes
220
46
G 3/4"a
SP2000/V20-0
20S9105
600
stainl. steel 316/316Ti
2
2-10
X
yes
220
46
G 3/4"a
SP2000/V20/HC
20S9095
900
Hastelloy-C
2
2-10
yes
220
46
G 3/4"a
SP2000/V20-0/HC
20S9115
900
Hastelloy-C
2
2-10
X
yes
220
46
G 3/4"a
SP2000/V20-T
20S9315
200
PTFE / stainl. steel 316TI
3
> 10
yes
4)
400
65
G 3/4"a
SP2000/V20-2
20S9125
600
stainl. steel 316/316Ti
2
> 10
yes
520
60
G 3/4"a
SP2000/V20-1
20S9145
600
stainl. steel 316/316Ti
2
> 10
X
yes
520
60
G 3/4"a
SP2000/V20-2/HC
20S9135
900
Hastelloy-C
2
> 10
yes
520
60
G 3/4"a
SP2000/V20-1/HC
20S9155
900
Hastelloy-C
2
> 10
X
yes
520
60
G 3/4"a
SP2000/V20-4
1)
20S9290
600
stainl. steel 316/316Ti
2
2-10
yes
1)
300
31
G 3/4"a
SP2000/V20-3
1)
20S9300
600
stainl. steel 316/316Ti
2
2-10
X
yes
1)
300
31
G 3/4"a
SP2000/V20-5
20S9127
500
stainl. steel 316/316Ti
3
2-10
yes
4)
220
50
G 3/4"a
SP2000/V20-6
20S9128
500
stainl. steel 316/316Ti
3
> 10
yes
4)
520
60
G 3/4"a
SP2000/V12-1
20S9500
1000
ceramik
5)
/stainl. steel 316Ti
1
> 10
yes
4)
500
40
DN65 PN6
SP2000/V12-3
20S9510
1000
ceramik
5)
/stainl. steel 316Ti
1
> 10
optional
yes
4)
1000
60
DN65 PN6
SP2000/V12-2
20S9505
1000
ceramik
5)
/stainl. steel 316Ti
2
> 10
optional
yes
1000
60
DN65 PN6
SP2000/V12-1/SS
2)
20S9525
600
ceramik
5)
/stainl. steel 316Ti
1
> 10
yes
4)
500
40
DN65 PN6
SP2000/V12-3/SS
3)
20S9535
600
ceramik
5)
/stainl. steel 316Ti
1
> 10
optional
yes
4)
1000
60
DN100 PN6
SP2000/V12-2/SS
3)
20S9530
600
ceramik
5)
/stainl. steel 316Ti
2
> 10
optional
yes
1000
60
DN100 PN6
SP2000/V12-1/IC
2)
20S9540
1000
ceramik
5)
/ Incoloy - 316Ti
1
> 10
yes
4)
500
40
DN65 PN6
SP2000/V12-3/IC
3)
20S9550
1000
ceramik
5)
/ Incoloy - 316Ti
1
> 10
optional
yes
4)
1000
60
DN100 PN6
SP2000/V12-2/IC
3)
20S9545 1000
ceramik
5)
/ Incoloy - 316Ti 2
> 10
optional
yes
1000
60
DN100 PN6
1)
Prefilter V20-3, V20-4 optional up to 1000 mm length available.
2)
With protection tube V12-1.
3)
With protection tube V12-2/3.
4)
Prefilter with special construction for efficient back purge.
5)
Please pay attention to the characteristic feature of ceramic in case of high and changing temperatures!
Technical Data
C
Heated adaptor tube SP2000-H/AR
G
G
L1
Prefilter SP2000/20SS 150 with tube fitting and shape protection plate
G
35
L1
d1
L1
Extension tube SP2000/Vm...
G
G
Shape protection plate SP2000/AB..
L1
G
Vorfilter SP2000/V20 -0-1-2-3-4-5-6 mit angeschweißtem Gewindeanschluss
d1
L1
G
Prefilter SP2000/V12... with mounting flange adaptor
G
L1
d1
L1
d1
G
Tube prefilter SP2000/V20-T including support tube with thread connection
Prefilter SP2000/V20 -0-1-2-3-4-5-6 with welded thread connection
d1
L1
G
L1
Volume displacer V12-2/3
G
