4.3 CLIP NUMBERING HIERARCHY
Multicam can store up to 900 (multiplied by the number of cameras) clips and 100
playlists in its libraries. 900 clips with up to 6 camera angles per clip result in
5400 clips on a server. This number is displayed in the upper right window of the
VGA Setup screen (SHIFT + F2 from the PC keyboard).
The following diagram represents the hierarchy of the Multicam clip numbering
system. As an example, clip number “112” is used:
