3D
Availability The parameter is only available with V3X boards if a 3D option
has been subscribed to (license code 23 for 3D Dual Link).
Description Activates the 3D option, using the Dual Link. This option
makes it possible to use the server to record and play back 3D
video.
Values Yes / No (default).
3G/Dual
Description Defines the interface the EVS server will use with the 3D
standards:
• The Dual Link interface consists of a pair of HD-SDI serial
links and provides a bitrate of 2.970 Gbit/s.
• The 3G-SDI is not supported on an XSnano server.
Values The possible values are:
• ‘No’: available in all cases.
• ‘Dual’ (Dual-Link) available with:
◦ License code 23 (3D Dual-Link) active
AND
◦ 3D setting set to 'Yes'
Default value No
Port Settings
Introduction
The port settings allow assigning the RS422 ports to the various external controllers (EVS
or third-party) that will communicate with the EVS server.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Channels tab, in the advanced display mode
on page 1 on the server- and web-based interfaces.
• in the Technical menu of the Remote Control Panel (T2.X).
