Example
In the screenshot displayed below, the audio mono channels defined on the A/V material
on the EVS server are allocated to the play channels in the following way:
The audio outputs are in dolby embedded format.
By default, an audio mono channel of the A/V material stored the EVS server is sent to the
corresponding embedded channel of the play channel. In this example, this is the case for
mono channels from 3 to 8.
For mono channels 1 and 2, the default mapping has been changed as follows:
• The audio mono channel 1 of the A/V material is sent to the mono channel 2 of the play
channel, and this for all play channels.
• The audio mono channel 2 of the A/V material is sent to the mono channel 1 of the play
channel, and this for all play channels.
