Char out j4, Char out j1, Out b j3 – EVS XSnano Version 11.01 - November 2012 Configuration Manual User Manual
Page 124: Aspect ratio
Char OUT J4
Description
Specifies the monitoring output type generated on the J4
connector.
Values
•
SD
•
HD
Default value
System dependent
Char OUT J1
Description
Specifies the monitoring output type generated on the J1
connector.
Value
•
CVBS
OUT B J3
Description
Specifies the output type generated on the J3 connector.
Values
•
SD
•
HD
Default value
System dependent
Aspect ratio
Warning
A change to this parameter requires an application reboot (ALT+Q from the
operational windows) to be applied.
Description
Defines the frame ratio.
Values
•
4:3 L Box
•
4:4 crop
•
16:9
Default value
4:3 L Box
XSnano Server - Version 11.01 - Configuration Manual
3. Multicam Configuration
114
